XCMG Gtbz24A Electric Telescopic Boom Lift Platform Aerial Work Platform China
XCMG E-Commerce Inc.- Running Mode：Moving
- Other Country：Jiangsu, China, Cn;Jia
- Type：Telescoping Lift
- Transport Package：Well
- Specification：standard
- Trademark：XCMG
Base Info
- Model NO.：GTBZ24A
- Origin：China
Description
Items
Unit
Parameters
a. Overall length
mm
11280
b. Overall width
mm
2490
c. Overall height
mm
3000
d. Wheel base
mm
3000
Maximum working height
m
26.08
Maximum platform height
m
24.38
Maximum working amplitude
m
18.9
Maximum bearing capacity
kg
230
Luffing range of boom I
°
-1 to +70
Luffing range of boom II
°
-35 to +68
Slewing angle of slewing table
°
360°
Maximum tail wagging
mm
1330 (boom lifted)
Platform dimensions
mm
2400×900
Slewing angle of platform
°
180
Overall weight
kg
17800
Maximum traveling speed
km/h
5
Minimum turning radius
m
4.2m (four turns)/6.7m (two turns)
Minimum ground clearance
mm
260
Maximum gradeability
%
45
Tire specification
-
18-625
Engine model
-
QSF2.8 71BHP/KDI2504 TCR
Rated engine power
kW/(r/min)
53/(2200)/55.4/(2600)
