Driveable Mobile Stock Picker Stock Tray and Carry Deck Capacity 115kg
Jinan PLK Machinery Co., Ltd.- After-sales Service：Free Spare Parts Replacement
- Warranty：1 Year
- Motor：1.6kw
- Max. Lifting Height：2700mm, 3300mm, 4000mm, 4500mm
- Rated Loading Capacity：300kg
- Platform Size：600*640
Base Info
- Moving Method：Battery Moving
- Lifting Method：Hydraulic
- Usage：Aerial Work
- Lifting Speed：4-6m,Min
- Driving Speed：4km,H
- Min.Turning Radius：1500mm
- Max.Climbing Capacity：15~20%
- Driving Wheel Size：230*8mm
- Caster Size：6mm
- Driving Motor：2*24,0.4
- Lifting Motor：24,1.6
- Transport Package：Wrapped with Stretch Film
- Specification：1530*700*1830
- Trademark：PLK LIFT
- Origin：China
- HS Code：8428909090
- Production Capacity：5000
Description
Basic Info.
Moving Method Battery Moving Lifting Method Hydraulic Usage Aerial Work Lifting Speed 4-6m/Min Driving Speed 4km/H Min.Turning Radius 1500mm Max.Climbing Capacity 15~20% Driving Wheel Size 230*8mm Caster Size 6mm Driving Motor 2*24/0.4 Lifting Motor 24/1.6 Transport Package Wrapped with Stretch Film Specification 1530*700*1830 Trademark PLK LIFT Origin China HS Code 8428909090 Production Capacity 5000Product Description
10ft Self Propelled Electric Stock Picker Aluminum Aerial Order Picker
The stock picker also known as an order picker makes you improve efficiency, reach and safety in the warehouse.
Using a stockpicker from PLK to pick stock, perform general maintenance and expedite other repetitive tasks allows your staff to complete their work in less time.
It is a good alternative of your traditional ladders, a walkie stacker, a manual pallet jack or walk-behind truck.
This order pickers can help reduce storage costs and allow for more portable, productive warehouse operation.
| Model Type | OPC03M | |
| Max.Platform Height | mm | 3050 |
| Max. Working Height | mm | 4880 |
| Max. Machine Height | mm | 1460 |
| Ground Clearance (Pothole Protection) | mm | 15 |
| Max.Ground Clearance | mm | 50 |
| Platform Size | mm | 495X690 |
| Platform Entry Height | 360 | |
| Max.Drive Speed (platform Stowed) | km/h | 4.0km/h |
| Max.Drive Speed (platform Elevated) | km/h | 0.8km/h |
| Min.turning Radius | mm | 0.23 |
| Max.Climbing Capacity | % | 25% |
| Rear Driving & Steer Wheels | mm | 230x80mm |
| Non-Marking Caster Wheels | in | 8 in |
| Driving System | 4Brush Direct Electric (Planetary Gear) | |
| Battery | v/Ah | 2X12V/100Ah |
| Battery Charger | v/A | 24V/30A |
| Overall Width | mm | 830 |
| Overall Width(without bumper) | mm | 750 |
| Platform Capacity | kg | 160 |
| Carry Deck Capacity | kg | 113 |
| Material Tray Capacity | kg | 113 |
| Overall Net Weight | kg | 560 |
Product Show
Welcome to visit our factory and place the order with us
All our products are CE certificated, good quality and competitive price. Welcome to send the inquiry to us if you are interested in any of them, and we will reply you ASAP.
