• Model NO.：QY130k
• Origin：China
• HS Code：84294019
• Production Capacity：1000

Category
Item
Unit
Parameter
Main Lifting Performance
Max. total rated lifting capacity
t
130
Min. rated working radius
m
3
Turning radius at turntable tail (counterweight)
mm
4600
Max. load moment
Base boom
kN.m
5003
Fully-extended boom
kN.m
2090
Outrigger span
Longitudinal
m
7.56
Lateral
m
7.6(5.2)
Hoist height
Base boom
m
13
Fully-extended boom
m
58
Fully-extended boom +28m Jib
m
86
Boom length
Base boom
m
13
Fully-extended boom
m
58
Fully-extended boom +28m Jib
m
86
Jib offset angle
°
0, 15, 30
Working
Speed
Elevating time
Boom raising
s
60
Telescoping time
Fully extended
s
420
Fully retracted
s
400
Max. swing speed
r/min
1.8
Outrigger extending and retracting time
Outrigger
beam
Extending
Simultaneously
s
50
Retracting
Simultaneously
s
40
Outrigger
jack
Extending
Simultaneously
s
50
Retracting
Simultaneously
s
45
Hoist speed (single line, 4th layer)
Main winch
No load
m/min
115
Auxiliary winch
No load
m/min
115
Noise
Exterior noise level
dB (A)
≤118
Noise level at seated position
dB (A)
≤90
