• Model NO.：YH Model
• Certification：CE, ISO9001:2000
• Condition：New
• Color：Accoding to Your Demands
• Working temperature：-10~+60 Centigrade
• Max. Capacity：10t
• Max. Lifting Height：20m
• Power：Electric
• Control Methods：Accoding to Your Demands
• Standards：ISO China Standards
• Emergency Stop System：Including
• Traveling Reducer：Including
• Overload Protection Device：Including
• Transport Package：High Quality Plywood Box
• Specification：ISO standards
• Trademark：KUANGYUAN Brand
• Origin：Xinxiang, China Main Land
• HS Code：84251100
• Production Capacity：68000 Sets,Year

YHCapacity (t)23510Hoist Height(m)912151820912151820912151820912151820Hoist Speed(m/min)8(2/8)7(1.75/7)Travel Speed(m/min)20Track20a-30c25a-50b32b-50bWork DutyM6PowerAC380V 50HzThe High Quality 0.5t ~ 32t Electric Hoist  features include low maintenance, compact structure, sealed brakes, a two-speed hoist motor, and optional inverter control. Two-component epoxy paint is standard. The KUANG YUAN High Quality 0.5t ~ 32t Electric Hoists  are designed to meet and exceed either FEM or ISO standard and provide the ultimate in easy load handling, safe operation and lasting, trouble-free performance.

FEATURES
1. Hiest Efficiency, maximized usage of space
Hoist and trolley motors designed for space savings and productivity. Standard two-speed hoist motor (6:1 ratio), designed specifically for hoisting applications, offers high starting torque and ensures precise and reliable load handling. The most compact structure makes the application of Zhongan Low Headroom Electric Wire Rope Hoists cover a larger area in the same plant and working area, reducing dead spots. If requirements for the plant is designed according to the parameters, the requireents for the plant height will be significantly lowered, saving investment, improving efficiency and reducing cost for the customers.
2. Ease of Operation
Large-diameter hoist drum means easy positioning, closer approaches. The larger drum diameter provides near true vertical lift with a single reeved hoist. The result is exceptionally smooth movement and fast load positioning. This innovative design also means a shorter frame length, allowing closer end approaches.
The hoist motor is class F insulated, 30 minute rated (60% effective duty), thermally protected and totally enclosed.
3. Safety
Standard safety features of Low Headroom Electric Wire Rope Hoist including load limit switch prevents the lifting of loads that are in excess of 110% of rated capacity. The 4-position hoist limit switch includes phase mismatch protection circuit preventing the block from running up and damaging the hoist in the event of phase reversal. And there are also phase-loss, voltage-loss, over current etc. safety proection,
4. Less Maintenance
Aluminum alloy hoisting motor shell, light weight, anti-corrosion level IP55.  The trolley drive is totally enclosed, grease lubricated all service life and is designed to be maintenance-free. The automatic disc brake and inverter control help extend the life of the motor and other components, which means less maintenance, less downtime, lower repair costs - and reduced cost over the lifetime of your hoist equipment.
5. Long Life
Compact gearbox provides dependable operation and extends equipment life.  The gear case design reduces stress on drum bearings, reducing the need for maintenance while extending component life. It features hardened and ground internal reduction gears driving an external drum gear located on the inner surface of the rope drum. The gearbox's semi-fluid grease lubrication also helps to extend its working life.
We adopt seamless steel drum contain with rope groove. We use high strength linear contact wire rope, safety factor could meet 5 times safety lifting weight, with good anti-grind characteristic, long service life.
Welcome your inquiry on our electric hoist~
