Lifting Equipment Speed 0-66m/Min Sc200/200 Electormotor 3 Standard Construction Hoist
FANGYUAN GROUP CO., LTD.- After-sales Service:Provided
- Warranty:1year
- Rated Loading Capacity(Kg):2000,2000kg
- Hoisting Speed:0-66m,Min
- Dimension(L*W*H):650*650*1508mm
- Max Lifting Height:300m
Base Info
- Model NO.:SC200,200
- Electormotor Power:18.5kw*3,18.5kw*3
- Transport Package:Container
- Specification:2t
- Trademark:FYG
- Origin:Shandong, China
- HS Code:8428909090
- Production Capacity:30 Sets Per Month
Description
Technical parameters

Unit
SC200/200 Frequency Construction hoists Height m300
Rated load kg2000/2000 Maximum capacity 009/009 Boom lift wweight kg≤200 Lifting speed m/min 0-40 0-45 0-55 0-66 Electormotor Model YZEJ132M(L)-4Power
kw 15×2/15×2 11×3/11×3 15×3/15×3 18.5×3/18.5×3 Speed-limiter Model SAJ40-1.2A SAJ40-1.4 Rated tripping speed m/s 1.2/1.4 Standard motion speed m/s 1.1/1.35 Rated automaticload KN40
Type gradual Reducer Model SWC1 TU68T TU66T Center distancemm 125 Speed radio 1:12 1:10 Bracking distancem 0.3-1.2 Mast section dimensionmm 650×650×1508 Crane cage inner net dimensionm 3.0×1.3×2.2 3.2×1.5×2.2 Guardrail dimensionm 5.53×3.42×1.82 5.93×3.62×1.82 Hoistway dimensionsm Free end height of the guide rail framem ≤9 Gounterweight weightkg Direct attached frame Installing intervalm/set 006-9 Distance between two embedded partsmm ≈1488 Installation dimensions from center of rail frame to building wallmm 2800-3200 Safe and protection system Upper and below limited switches,upper and below limit utmost switches,gate limited switch,falling avoiding safe device,cushion device,safe lock of gate,counterweight rope breaking or loose protecting device,safe hook,The safety device against overload,Anti-punching standard section etc.
