• Model NO.：Gtbz26s
• Specification：10150*2490*2800mm
• Trademark：XCMG
• Origin：Jiangsu, China
• HS Code：84301000
• Production Capacity：1000,Year

Overview Product Description

Product Parameters



DescriptionUnitParameter valueOverall Lengthmm12100Overall Widthmm2490Overall Heightmm3050Wheel Basemm3000Maximum Working Heightm27.9Maximum Platform Heightm26.2Maximum Working Rangem23.2Maximum Load Capacitykg340Boom Luffing Range°-5~+75Crank Arm Luffing Range°-65~+70Rotation Angle of Rotating Platform°360Maximum Tail Waggingmm1400Platform Sizemm2.4×0.9/1.8×0.8Rotation Angle of Platform°180Total Weightkg16600Maximum Travel Speedkm/h6.1Minimum Turning Radiusm6.7Minimum Ground Clearancemm320Maximum Grade Ability%45Tire Specification-385/65-22.5Engine Model-QSF2.8-71HPRated Power of EnginekW/(r/min)53/(2200)Product Show



Company Profile



FAQ

1: What kind terms of payment can be accepted?

A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted

2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,

3: What about the delivery time?
A: 30 days after receiving the deposit.

4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.

5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
