Orange 3m Mini Manual Pushing Scissor Lift 240 Loading Capacity Easy Operation
Chenlift (Suzhou) Machinery Co., Ltd.- Application：Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
- Lift Mechanism：Scissor Lift
- Carrying Capacity：Middle-Level
- Moves：Moving
- Driven Type：Hydraulic
- Running Mode：Moving
Base Info
- Model NO.：MK300
- Certification：CE, ISO 9001
- Platform Height：3m
- Working Height：5m
- Loading Capacity：240kg
- Motor Power：0.8kw
- Transport Package：PVC Film Wrapped in Pallet
- Specification：1.3*0.76*1.43m
- Trademark：CHEN LIFT
- Origin：China
- HS Code：8428909090
- Production Capacity：2000 Units Per Year
Description
Description:
This mini scissor lift is easy to use. The control panels are available on the platforms and ground.
The user can control the machine walking and lifting operation directly on the platform, and realize the single person working continuously at high altitude.
Because it is miniature, the height is limited, suit low position aerial work. They are used to provide contractors with temporary access to high-altitude areas that are inaccessible to various workplaces, such as maintenance, construction projects or fire crews emergency access.
The scissor structure enables reliable stability when the lifts rising up, the broad platform and the high loading capacity get the aerial working more efficient and more safely.
Main Features:
1. Pointing control of lifting up and down.
2. Manganese steel lifting arm in high strength with rectangle shape
3. Anti skid floor in platform
4. The control panels are available on the platforms and ground.
5. Fine grinding cylinder in good sealing performance
6. Neatly folding guardrails
7. Battery and battery charger in bulit
8. Optional extension platform
Major Parameters
- Model: MK300
- Loading Capacity 240kg
- Maximum Height 3000mm
- Minimum Height (rails up) 1830mm
- Minimum Height (rails down) 1430mm
- Platform Size 1150*700mm
- Lifting Power 0.8kw
- Power Voltage DC12V
- Raise / Lower Time 34s / 20s
- Total Weight 482kg
- Overall Size 1300*760*1830mm
Configurations:
- Electric system: Schneider contactor, SANLICO button, CHNT electrical
- Hydraulic System: Hycman brand power pack ,NOK sealing
- Scissor Arm Support: Hi-strength Manganese steel rectangle tube Q345 B
- Platform Surface : Antiskid checkered plate
- Tyre: 6inch and 8inch, two swivel and two fixed
- High-pressure Oil Pip: Double wire hydraulic intensifier rubber hose
Safety Precautions
1. The operation voltage on the platform is 24V
2. Emergency stop button on the platform and ground
3. Auxiliary platform lowering
4. Hose burst valve safety
5. Rain-proof design electric cabinet
6. Fold-able fence on the platform
Applications:
1. Site: Work Shop, Theatre, Hospital, Library, Restaurant, Hotel Exhibition Hall etc.
2. Aerial Working Purpose: machine maintenance, painting, cleaning etc.
Why choose Bestmax Mobile Scissor Lift?
- High Quality
- Reasonable Price
- Good after Service
- 1 Year Warranty
- More Than 10 Years Experience
Company Introduction
Chenlift (Suzhou) Machinery Co Ltd. is a Suzhou-based world-wide supplier of lifting equipment with over 20 years of experience in the lifting industry, we have the knowledge to assist you in acquiring your next lifting equipment.
We specialize in producing in a range of aerial lift and aerial work platform equipment for your unique application.
We have established distributor relationship with customers from over 30 countries and regions in Southeast Asia, Middle East, South America,Europe and Africa
Fabrication Equipment:
Communication with Customers
A: What is the difference from mobile scissor lift and mobile aluminum aerial work platform?
B: The main difference is from the structure and the material
The scissor lift is in scissor structure with steel material
The aerial work platform is in mast structure with aluminum material
A: How is that for quality control in your factory?
B: The quality control is strictly in accordance with ISO9001 quality management system. When the products are finished, the inspection is 100% executed strictly
1.Strict quality control system on the whole process of production
2.Imported key arts to ensure the high quality of our products
3.Advanced equipment and tools for examination and quality control
4.100% strict examining products before shipment
5.All the quality complaints and improvement requirements are always studied seriously, if reasonable, put into practice immediately.
A: What is the delivery time for your goods?
B: it is 30days after order confirmation
A: What spare parts that you can offer?
B: We provide following spare parts freely for your maintenance of the machine:
A: How long is your quality guarantee period?
B: We have one year warranty.
