• Feature：Explosion-Proof
• Certification：CE, ISO 9001
• Platform：Antiskid
• Max Load Capacity：1000kg -4000kg
• Installation：in a Pit
• Lifting Point：Four Points for Easy Hoist
• Guardrail(Optional)：1100mm
• Lift Speed：3-6m,Min
• Surface：Rust-Proof
• Painting：Epoxy Paint
• Voltage：220V,380V, AC Power, 1 or 3 Phase, Can Also Be Mad
• Color：Yellow, Blue, Green, Black as Your Requirement
• Transport Package：Plywood Case
• Specification：CE
• Trademark：MORN
• Origin：Jinan, China
• HS Code：84289090
• Production Capacity：10, 0000PCS,Years

Basic Info.

Feature Explosion-Proof Certification CE, ISO 9001 Platform Antiskid Max Load Capacity 1000kg -4000kg Installation in a Pit Lifting Point Four Points for Easy Hoist Guardrail(Optional) 1100mm Lift Speed 3-6m/Min Surface Rust-Proof Painting Epoxy Paint Voltage 220V/380V, AC Power, 1 or 3 Phase, Can Also Be Mad Color Yellow, Blue, Green, Black as Your Requirement Transport Package Plywood Case Specification CE Trademark MORN Origin Jinan, China HS Code 84289090 Production Capacity 10, 0000PCS/Years

Product Description

Electric operated mobile scissor lift

Single scissor lift tables with 1000kg lift capacity.The lift tables can be mounted on the floor or in a pit.They are fully tested prior to despatch and are ready to use when delivered.Each table is CE marked and complies with the requirements of EN 1570-1 + A1, 2nd version 2014-10-09.Accessories are available to order, including extra hand controller, limit switch, bottom frame with wheels and tuck frame.And it is designed for material handling and all kinds of assembly line.


Safety Features:
--24V AC push-button hand control
--Electric toe guard to protect pinch points during lowering of the table
--Upper travel limit switch to stop table at maximum height reducing motor wear.
--Explosion-proof valve to maintain platform lowering down slowly in event of hydraulic pipe split.
--Safety maintenance props
--Powder coating appearance

Spec.
