• Model NO.：ZCC2600
• Tower Attachment Length：21-60 M
• Gradeability：30%
• Size：10.36*3.4*3.0 M
• Engine Power：227 Kw
• Max Mass of Single Unit：32 T
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：ORIEMAC
• Origin：Jiangsu, China(Mainland)
• HS Code：84295212
• Production Capacity：800PCS,Month

 ItemUnitValueRemarksMaximum lifting capacity × radiust × m260 × 5 Deadweight of crane with basic boomt210 Length of main boomS-boom lengthm20-83 SL-boom lengthm86-95 F-jib lengthm12-30 Max.lifting capacity on fixed jibt34 F-jib angle.10,30 Max. length of heavy duty boom with fixed jibm77+30 W-jib Length m21-60 Max. lifting capacity on luffing jibt73.5 S-boom angle( for SW boom configuration).65-85 Max. length of heavy duty boom with luffing jibm62+60 Single rope speed of winchesHoisting winch 1m/min130on the 6^thHosting winch 2m/min120Main boom derricking winchm/min80Slewing speedrpm0-1.2 Traveling speedkm/h0-1.0 Max.gradeability%30 Ground pressureMPa0.115 Transport weight of max.single unitt32Excluding  hoisting winches,titling-back support of main boom.A-frame and derricking mechanismRear counterweightt83.7 Central counteweightt32 EngineManufacturer US Cummins Rated power/rotational speedKw/rpm227/2000 Max. output torque/rotational speedNm/rpm1505/1400 Emission standard U.S.EPA Tier 3 and EU Stage III A
