Gtbz26s 26m Hydraulic Lifttelescopic Aerial Work Platform
Xuzhou Construction Machinery Group Co., Ltd.- After-sales Service:Overseas Service Center Available
- Warranty:1year
- Maximum Working Height:27.9m
- Maximum Platform Height:26.2m
- Maximum Working Range:23.2m
- Maximum Load Capacity:340kg
Base Info
- Model NO.:GTBZ26S
- Total Weight:16600kg
- Maximum Travel Speed:6.1km,H
- Transport Package:Container
- Specification:12100*2490*3050mm
- Trademark:XCMG
- Origin:Jiangsu, China
- HS Code:87059091
- Production Capacity:1000 , Year
Description
Item | Unit | Parameter |
a Overall Length | mm | 12100 |
b Overall Width | mm | 2490 |
c Overall Height | mm | 3050 |
d Wheel Base | mm | 3000 |
Maximum Working Height | m | 27.9 |
Maximum Platform Height | m | 26.2 |
Maximum Working Range | m | 23.2 |
Maximum Load Capacity | kg | 340 |
Boom Luffing Range | ° | -5~+75 |
Crank Arm Luffing Range | ° | -65~+70 |
Rotation Angle of Rotating Platform | ° | 360 |
Maximum Tail Wagging | mm | 1400 |
Platform Size | mm | 2.4×0.9/1.8×0.8 |
Rotation Angle of Platform | ° | 180 |
Total Weight | kg | 16600 |
Maximum Travel Speed | km/h | 6.1 |
Minimum Turning Radius | m | 6.7 |
Minimum Ground Clearance | mm | 320 |
Maximum Grade Ability | % | 45 |
Tire Specification | - | 385/65-22.5 |
Engine Model | - | Foton CumminsQSF2.8-71HP |
Rated Power of Engine | kW/(r/min) | 53/(2200) |





FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 30 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
