• Model NO.：GTWY
• Driven Type：DC
• Running Mode：Moving
• Feature：Explosion-Proof, Insulating
• Certification：CE, RoHS
• Transport Package：to Be Negotiated
• Specification：1.4m*0.82m*1.98m
• Trademark：PLK LIFT
• Origin：China
• HS Code：8428909090
• Production Capacity：500PCS,Year

Basic Info.

Model NO. GTWY Driven Type DC Running Mode Moving Feature Explosion-Proof, Insulating Certification CE, RoHS Transport Package to Be Negotiated Specification 1.4m*0.82m*1.98m Trademark PLK LIFT Origin China HS Code 8428909090 Production Capacity 500PCS/Year

Product Description

Self Propelled Single Mast Mobile Aluminum Man Lift
Features
Lower control panel-charging power indicator, charging status indicator, key switch (upward control for upper left, off for level, lower control for lower left), emergency stop button, toggle switch for up or down, power indicator 3. Use the time meter.

The upper control is the coordinated control of the handle and buttons-you can operate the handle to increase, decrease, turn, set the machine parameters, etc.

The turning radius of the front wheel drive is relatively small, and you can turn 360 degrees. If it is rear wheel drive, he will have uneven gravity distribution, because the motor of the driving wheel, including aluminum alloy and counterweight, are on the rear side.

The battery is fully charged once, and it can walk nine kilometers under full load. Then, it can be lifted 73 times and can work continuously for five hours.

 Datasheet


Model	GTWY6-1	GTWY7.5-1	GTWY7.5-2	GTWY9-2
Max. Working Height	8.00m	9.50m	9.50m	11.00m
Max. Platform Height	6.00m	7.50m	7.50m	9.00m
Loading Capacity	150kg	125kg	200kg	150kg
Occupants	1	1	1	1
Overall Length	1.40m	1.40m	1.46m	1.46m
Overall Width	0.82m	0.82m	1.01m	1.01m
Overall Height	1.98m	1.98m	1.98m	1.98m
Platform Dimension	0.78m×0.70m	0.78m×0.70m	1m×0.65m	1m×0.65m
Wheel Base	1.14m	1.14m	1.14m	1.14m
Turning Radius	0	0	0	0
Travel Speed(Stowed)	4km/h	4km/h	4km/h	4km/h
Travel Speed(Raised)	1.1km/h	1.1km/h	1.1km/h	1.1km/h
Up/Down Speed	43/35sec	48/40sec	48/40sec	43/35sec
Gradeability	25%	25%	25%	25%
Drive Tyres	Φ305×100mm	Φ305×100mm	Φ305×100mm	Φ305×100mm
Drive Motors	2×12VDC/0.5kW	2×12VDC/0.5kW	2×12VDC/0.5kW	2×12VDC/0.5kW
Lifting Motor	24VDC/1.3kW	24VDC/1.3kW	24VDC/1.3kW	24VDC/1.3kW
Battery	2×12V/100Ah	2×12V/100Ah	2×12V/100Ah	2×12V/100Ah
Charger	24V/15A	24V/15A	24V/15A	24V/15A
Weight	1120kg	1190kg	1270kg	1345kg
