• Model NO.：ZS1623RT
• Driven Type：AC
• Running Mode：Moving
• Feature：Explosion-Proof, Insulating
• Certification：GS, CE, RoHS, ISO 9001
• Trademark：H&L
• Origin：China
• HS Code：8429521200
• Production Capacity：50000,Year

Overview Product DescriptionZS1623RT MetricImperialSizeWork Height18m59ftA Platform Height-Elevated16m52ft 6inB Platform Height-Stowed2.03m6ft 8inC Platform Dimension (Length)3.98m13ft 1inD Platform Dimension (Width)1.83m6ftPlatform Extension1.3m4ft 3inOverall Height (Rails Up)3.16m10ft 4inE Overall Height (Rails Down)2.47m8ft 1inF Overall Length4.88m16ftG Overall Width2.3m7ft 7inH Wheelbase2.9m9ft 6inI Ground Clearance0.275m11inPerformancePlatform Capacity680kg1500lbCapacity on Deck Extension230kg510lbDrive Height9m29ft 6inMax. Number of Workers4Drive Speed (Stowed)6.5km/h4mphDrive Speed (Raised)0.5km/h0.3mphTurning Radius (Inside)2.75m9ftTurining Radius (Outside)5.8m19ftUp/Down Time60/65s60/65sGradeability40%Max. Working Slope (Lateral/Vertical)2°/3°Drive4WDBrake315/55 D20 Foam-filled Tires











Company Profile



Our Advantages

OUR SERVICE
1)Professional fast response mechanical engineers and electrical engineers provide suitable solution method for you all around the world.
2)Engineers available to reach machinery overseas job site at any time required.
3) Technical Support of installation/training supplied to help customers to earn most profits with our machinery.
4) All variety of spare parts available to support the customer 24h*7days for the daily maintenance/repair purpose etc.
OUR PRICE
We work as the leading VIP dealers of various famous Chinese construction machinery manufacturers and are constantly treated with best price policy which is only provided to special internal high level permission.From numerous comparison and feedback from clients.Our price is always more competitive and much favorable than the customer buy directly from manufacturers.
OUR PRODUCTS
Established in 2010, Anhui heavy and light industries International Group, which is located in Hefei City, the provincial capital of Anhui Province, China, has business for construction machinery,international trade, finance investment and education.
As the leading construction machinery exporter in China. We has over 100 countries international business and the annual sales figure exceeds USD 100 million.
It is an important export partner of the world famous brands such as SINOTRUK,SHACMAN,North BEIBEN,DONGFENG,FOTON,,ZOOMLION,HELI,CAMC,SDLG,SEM,LONGKING,LIUGONG,HANGCHA,HYUNDAI,DOOSAN,YTO,CIMC,etc. And manages the export of spare parts for these products with a stable customers network and good reputation worldwide.


FAQ
1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted
2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,
3: What about the delivery time?
A: 7-20 days after receiving the deposit.
4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.
5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs
