Txk 1ton Electric Chain Hoist with Trolley

Jiali Machinery Co., Ltd.
  • Application：Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane, All Situations
  • Type：Electric Hoist
  • Sling Type：Chain
  • Lift Speed：2~8m,min
  • Maximum Lifting Height：>20m
  • Chain Falls：1

Base Info

  • Model NO.：SSDHL01-01M
  • Certification：CE, ISO9001:2000
  • Condition：New
  • Color：Please Offer Us The Pantone Which You Would Like
  • Feature：Insulating
  • Running Mode：Moving
  • Structure：Hook Crane
  • Installation：All-Terrain Crane
  • Type of Work：Middle-Level
  • Transport Package：Plywood Case, Plastic Case
  • Specification：1ton 1,1
  • Trademark：TXK
  • Origin：Jiangsu, China
  • HS Code：8425110000
  • Production Capacity：1000PCS Per Month

Description

Basic Info.

Model NO. SSDHL01-01M Certification CE, ISO9001:2000 Condition New Color Please Offer Us The Pantone Which You Would Like Feature Insulating Running Mode Moving Structure Hook Crane Installation All-Terrain Crane Type of Work Middle-Level Transport Package Plywood Case, Plastic Case Specification 1ton 1/1 Trademark TXK Origin Jiangsu, China HS Code 8425110000 Production Capacity 1000PCS Per Month

Product Description

SSDHL01-01M  Electric Chain Hoists specifications:

Model01-01
Capacity (t)1
Lifting speed (m/min)6.6
Motor power (kw)1.5
Rotation speed (r/min)1440
Insulation gradeF
Power supply3P 220V-690V
Control voltage24V/36V/48V
No. of chain1
Spec. of load chain7.1
Net weight (kg)61




Details of Electric Chain Hoists:

1. Electric motor partial outer cover
They are made of high strength aluminum system through compression casting formation.
Features: Solid and light, Fast release heat, Continuous use, Enclosed structure. Can be used in the chemical plants, electroplating factories, and other places.
2. Side kind braking
This masterly structure ensure the hoist absolutly safety when the power off. And ensures it is safe when has excess load. Also it combine to the motor braking as the double brake system to strengthen security and durability.
3. Gear
The gear made of alloy steel and through the heat treatment
4. Antiphase protector
Advatages: When power-supply wiring mistake, the control circuit is unable to move.
5. Hooks
They are made by hot forging and heat treatment.
6. Chain
It is made of FEC80 ultra strong heat treatment alloy steel.
Advatages: It is safely approximately when used in the rain water, the sea water, under the chemical and other bad conditions.
7. ISO: M4 /FEM: 1AM
Insulation grade: F
8. Protection class (hosit and push button): IP54
9. Powder supply: 3 phase, 200-600V, 50Hz
10. Noise (single/ double speed): 81dB.
