CCS ABS BV Certification Single/Double Drum Electric Hydraulic Chain Rope Lifting Anchor Windlass

HENAN NYBON MACHINERY CO., LTD.
  • After-sales Service：Online Instruction,Engineers Available to Service
  • Warranty：1 Year
  • Type：Anchor Windlass
  • Driven Type：Electric, Hydraulic , Diesel Engine
  • Speed：Customization
  • Carrying Capacity：Weight Level

Base Info

  • Tonnage：1-100t
  • Reel Number：Customization
  • Running Mode：Stationary
  • Feature：Antiseptic
  • Certification：GS, CE, ISO 9001
  • Standard：National Standards
  • Function：Anchoring, Towing, Mooring
  • Rope Capacity：100-3600m
  • Color：Customized
  • Power Supply：380V 50Hz Three-Phase
  • Material：Q235B,Q345b
  • MOQ：1 Set
  • Structure：Single or Double Drum
  • Advantage：Compact Structure, Durable Product
  • Transport Package：Wooden Package & Container
  • Specification：20KN, 30KN, 50KN, 80KN, 100KN, etc.
  • Trademark：NYBON
  • Origin：Henan Province, China
  • Production Capacity：100 Sets Per Month

Description

Model

Chain dia.

(mm)

Working load

(KN)

Overload pulling force(KN)

Holding load

(KN)

Nominal speed(m/s)Drum load(KN)Nominal speed(m/s)Rope capacity(m)Warping load(KN)AM2AM3AM2AM3AM2AM3NYZ-17.517.51314.6 19.5 21.9 80 115 0.15 10 0.17 φ11*100 8 NYZ-191915.3 17.2 23 25.8 95 135 0.15  15 0.17 φ13*10010 NYZ-202017.920 26.9 30 110 157 0.15 200.17 φ13*100 10 NYZ-222220.6 23 30.9 34.5 126 180 0.15  20 0.25 φ15*100 15 NYZ-2424 24.5 27.4 36.8 41.1 149 214 0.15  20 0.25 φ15*10020 NYZ-2626 28.7 32.1 43.1 48.2 175 250 0.15  20 0.17 φ22*100 20 NYZ-28 28 33.3 37.2 50 55.8 202 289 0.15  20 0.17 φ22*100 20 NYZ-3030 38.3 42.8 57.5 64.2 231 330 0.15

30

0.17 φ22*100 30 NYZ-32 32 43.5 48.6 65.3 72.9 261 374 0.15  30 0.15 φ20*100 30 CCS ABS BV Certification Single/Double Drum Electric Hydraulic Chain Rope Lifting Anchor WindlassCCS ABS BV Certification Single/Double Drum Electric Hydraulic Chain Rope Lifting Anchor WindlassCCS ABS BV Certification Single/Double Drum Electric Hydraulic Chain Rope Lifting Anchor WindlassCCS ABS BV Certification Single/Double Drum Electric Hydraulic Chain Rope Lifting Anchor WindlassCCS ABS BV Certification Single/Double Drum Electric Hydraulic Chain Rope Lifting Anchor Windlass

1. Q: What's your MOQ?

  A: 1 Set;

2. Q: What's your package?

  A: Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes;

3. Q: What's your delivery period?

  A: Within 10/25/40 days after your prepayment received; exact period should be based on detailed requirements and
actual period;

4. Q: What's your warranty period?

  A: 12 months from winches accepted;

5. Q: Do you have engineer oversea installation service?

   A: Yes; We have;

6. Q: What kinds of products do you have?

    A: All kinds of industrial electric winch (especially non-standard); Overhead Crane; Gantry Crane, Electric Hoist;
Screw Hoist; Radial/Flat Gate Hoist; Steel Gate; etc.

7. Q: Do you provide lift tools?

    A: Yes, we can provide any kinds of lift tools such as lift sling belt, lift clamp, grab, magnet , pulley blocks, hook,
lock catch, wire rope, fiber rope, etc.

8. Q: Could your winches drag inclined?

    A: Yea, our electric winches could drag horizontal, drag inclined, hoisting vertical.
