• Model NO.：ATB0.2-16
• Feature：Water-Proof
• Certification：CE, ISO 9001
• Loading Capacity：200kg
• Self-Weight：2800kg
• Transport Package：Container
• Specification：7200*1800*2400mm
• Trademark：MORN LIFT
• Origin：Shandong, China
• HS Code：842890
• Production Capacity：30

Basic Info.

Model NO. ATB0.2-16 Feature Water-Proof Certification CE, ISO 9001 Loading Capacity 200kg Self-Weight 2800kg Transport Package Container Specification 7200*1800*2400mm Trademark MORN LIFT Origin Shandong, China HS Code 842890 Production Capacity 30

Product Description

Platform size: 900*700mm
Lift height: 16m
Max. work height : 17.8m
Working Radius: 7.0m
14m: two-section telescopic boom
Lift power:Petrol engine lift power(The petrol engine we use is HODNA,it is imported from Japan)
Diesel engine lift power,Battery lift power,Electric lift power or double power, such as petrol engine and electric lift power. Boom Lift control Boom lift have two controllers, one controller at top platform, the other one at the chassis of boom lift. So we could control boom lift easily.
Balance sensor/ Level sensor/system
The light is green(balance),the lift can start to work
The light is red(unbalance),the lift do not to work
Safety Sensor
Outriggers  :
Guarantee the boom lift and worker safety during working.
Boom lock
Towable boom lift, prevent boom sway during boom moving, in case of boom lift damage.
Balance valve
There is a balancing valve on each hydraulic cylinder.And Boom lift with balance valve imported from Italy.
One function, Prevent boom lift down, in case of the hydraulic oil pipe damaged and pres-relief.
another function is emergency down.(If power cut off, in order to guarantee worker safety, boom lift could be down by manual.)
Hydraulic lock
Each outrigger installed one hydraulic lock, prevent outrigger back, in case of the hydraulic oil pipe damaged. It will protect worker safety at top platform
Warning Alarm
During boom lift work, warning alarm will work to remind surround people mind safety
Emergency stop
Each controller with one emergency stop, we could stop the boom lift work under any emergency situation.
Turntable system
Turntable system is waterproof and could be rotated 360⁰.
Guarantee the boom lift stability during rotation,waterproof and dust proof.IP65
The platform with protect bar to protect the hand from clamping, if the platform near the any obstacle.
The trailing system was imported from Italy.The function of the small wheel is to control the direction while the machine is moving manually.But it will raise up  when it's pulled by a truck.
Double brake system
One brake line connect to the truck, if the truck stop, boom lift will stop against inertia
One brake by electric, if the truck brake light work, boom lift wheel brake work.

Trailer has need special tow hook, connect with trucking well, and move or turning smoothly.

Four hydraulic outriggers open and support wheel leave ground to prevent the machine from tilting during the work.
