• Model NO.：SJY
• Running Mode：Moving
• Feature：Explosion-Proof, Insulating
• Certification：GS, CE, RoHS, ISO 9001
• Voltage：Customized
• Transport Package：Standard
• Trademark：PLK LIFT
• Origin：China
• HS Code：8428909090
• Production Capacity：500sets

Basic Info.

Model NO. SJY Running Mode Moving Feature Explosion-Proof, Insulating Certification GS, CE, RoHS, ISO 9001 Voltage Customized Transport Package Standard Trademark PLK LIFT Origin China HS Code 8428909090 Production Capacity 500sets

Product Description

------------------------------------------------------------------

Click "Contact Supplier" Below to Inquire..

------------------------------------------------------------------

Scissor Lift China Scissor Lift Equipment Push Mobile Scissor Lift
Electric scissor lift comes with  CE certificate, which is a must in aerial working industry. Equipped with two fixed wheels and two universal ones, the moving and turning job is easily done.
It has power failure self locking function and emergency descent system guaranteeing the worker safety.
There're multipe power sources for you to choose from, AD, DC Or the two combined, all tailored to your needs and all you need to do is ask.

Model No.	Loading Capacity (kg)	Lifting Height (m)	Platform Size (m)	Overall size (m)	Motor (kw)	Wheels(φ)	Net Weight (kg)
SJY4506-H	450	6	1.85*0.88	1.95*1.08*1.1	1.5	200 PU	800
SJY4507-H	450	7.5	1.8*1.0	1.95*1.2*1.54	1.5	400-8 Rubber	1000
SJY4509-H	450	9	1.8*1.0	1.95*1.2*1.68	1.5	400-8 Rubber	1200
SJY4511-H	450	11	2.1*1.15	2.25*1.35*1.7	2.2	500-8 Rubber	1580
SJY4512-H	450	12	2.45*1.35	2.5*1.55*1.88	3	500-8 Rubber	2450
SJY4514-H	450	14	2.45*1.35	2.5*1.55*2.0	3	500-8 Rubber	2650
SJY1006-H	1000	6	1.8*1.0	1.95*1.2*1.45	2.2	500-8 Rubber	1100
SJY1009-H	1000	9	1.8*1.25	1.95*1.45*1.75	3	500-8 Rubber	1510
SJY1012-H	1000	12	2.45*1.35	2.5*1.55*1.88	4	500-8 Rubber	2700
SJY0316-H	300	16	2.75*1.5	2.85*1.75*2.1	3	500-8 Rubber	3200

------------------------------------------------------------------

Click "Contact Supplier" Below to Inquire..

------------------------------------------------------------------

CE certification
Simple structure, easy to maintain.
Manual pulling, two universal wheels, two fixed wheels, convenient for moving and turning
Moved by man or towed by tractor. Lifting by AC(without battery) or DC (with battery).
Electrical protection system:
a. The main circuit is equipped with main and auxiliary double contactors, and the contactor is faultless.
b. With limit switch.
c. Equipped with emergency stop button on the platform
d.Power failure self-locking function and Emergency descent system

------------------------------------------------------------------
