Shanding China 6m 8m 10m 12m 14m Electric Hydraulic Self Propelled Mobile Aerial Work/Working Lift/Lifting Light Platform

Shandong Davoo Machinery Co., Ltd.

After-sales Service：Video Technical Support;Online Support;Free Spare
Warranty：1 Year
Application：Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
Lift Mechanism：Scissor Lift
Carrying Capacity：Special Weight Level
Moves：Vehicular

Base Info

Model NO.：GTJZ-12SD
Driven Type：Hydraulic
Running Mode：Moving
Feature：Explosion-Proof, Insulating
Certification：CE, ISO 9001
Transport Package：Container
Specification：2495*1187*2050mm
Trademark：shanding
Origin：Shandong
HS Code：8428909090
Production Capacity：100 Sets,Week

Description

Model (self-hydraulic drive)GTJZ12The maximum working height13.80mMaximum platform height11.80mSafe working load320kgExtended platform safe working load113kgWorking platform size ( length ×width×height)2.29×1.13×1.1mOverall dimensions ( length × width × height,
(The guardrail is not folded)2495*1187*2585mmOverall dimensions ( length × width × height,
Folding guardrail)2495*1187*2050Table extension size0.9mMinimum ground clearance0.1/0.02mWheelbase1.89mTurning radius (inner wheel/outer wheel)0/2.2mLifting / driving motor24V/4.5kwLifting speed3-5m/minMachine travel speed (closed state)3.5km/hMachine speed (lifting state)0.8km/hAccumulator4×12V/300ahcharger24V/30AMaximum climbing ability25%Maximum allowable angle of work1.5°/3°tireΦ 381×127 mmTotal Weight2960kg Shanding China 6m 8m 10m 12m 14m Electric Hydraulic Self Propelled Mobile Aerial Work/Working Lift/Lifting Light Platform
