1ton 2ton 3ton 5ton 10ton Monorail Electric Wire Rope Hoist
Henan Kuangshan Crane Co., Ltd.- After-sales Service：on Line
- Warranty：1 Year
- Application：Double Beam Crane, Gantry Crane, Bridge Crane, Single Grinder Crane, Mineral Area Workshop Container Construction Usage
- Type：Electric Hoist
- Sling Type：Wire Rope
- Lift Speed：2~8m,min
Base Info
- Model NO.：CD, MD
- Maximum Lifting Height：>20m
- Chain Falls：2 or 4
- Certification：CE, ISO9001:2000, ISO9001: 2000, CE
- Condition：New
- Color：According Toyour Requirement
- Weight Overload Protection Device：Include
- ISO900 Ce：Pass
- Working Class：A3 A4
- Rope Type：Steel Wirerope
- Current Overload Protection System：Include
- Lifting Limit Switch：Include
- Power Type：Electric
- Power Source：380V50Hz3phac or Customized
- Moving Type：Wheel
- Installation：Assembled
- Painting Color：According to Your Demand
- Steel：Q235
- Gear,Shaft：45# or 50# Steel
- Bearing：China Famous Brand
- Gravity Limit Switch：Include
- Transport Package：Packed by Plywood Crate All by Export Standard
- Specification：A3 A4
- Trademark：KUANGYUAN
- Origin：Xinxiang, Henan Province
- HS Code：84251100
- Production Capacity：28, 000 Sets,Year
Description
Capacity (ton)
0.5
1
2
3
5
10
16
20
Lifting height (m)
6, 9, 12, 18,24,30
Working duty
M3
M6
Control way
Pendant control, or Remote control
Power source
380V 50HZ 3phase (Could supply it as yours)
I-beam type
16-28b
20a-32c
25a-63c
45a-63c
Lifting mechanism
Electric hoist model
CD1 single speed, MD1 double speed
Wire rope
Diameter
4.8
7.4
11
13
15
15
17.5
20
Structure form
D-6×37+1
Lifting speed (m/min)
Single
8
7
3.5
Double
0.8 / 8
0.7 / 7
0.35/3.5
Motor power (KW)
Single speed
0.8
1.5
3
4.5
7.5
13
13
18.5
Double speed
0.2/0.8
0.2/1.5
0.4/3
0.4/4.5
0.8/7.5
1.5/13
1.5/13
3.0/18.5
Rotation speed (n/min)
1380
1400
Traveling mechanism
Traveling speed (m/min)
20 or 30
Motor power (KW)
0.2
0.2
0.4
0.4
0.8
2×0.8
2×0.8
4×0.8
Rotation speed (n/min)
1380
