• Model NO.：GTBZ20AE
• Feature：Explosion-Proof
• Certification：CE, ISO 9001
• Max.Working Height：20.23m
• Max.Platform Height：18.23m
• Max.Horizontal Reach：11.14m
• Ground Clearance：0.34m
• Wheel Base：2.60m
• S.W.L：230kg
• Transport Package：Nude Package
• Specification：8.61m*2.49m*2.44m
• Trademark：DINGLI
• Origin：Zhejiang, China
• HS Code：8427109000
• Production Capacity：1000units,Year

ModelGTBZ20AEMax.Working Height20.23mMax.Platform Height18.23mMax.Horizontal Reach11.14mMax.Horizontal Reach7.65mOverall Length(Stowed)8.61mOverall Length(Transport)6.71mOverall Width2.49m/2.30mOverall Height2.44m/2.45mPlatform Size2.20m×0.80mGround Clearance0.34mWheel Base2.60m ModelGTBZ20AES.W.L230kgMax.Occupants2Turntable Tailswing0.63mTurning Radius(Inside/Outside)3.37m/5.37mTurret Rotation360°continuousPlatform Rotation±90°Jib Movement+70°/-60°Travel Speed(Stowed)6.1km/hTravel Speed(Working)≤1.1km/hGradeability40%Maximum Slope5°Tyre315/55 D20 ModelGTBZ20AEBatteries48V/320AhIntegrated Charger48V/60ADrive MotorAC 48V/3.3kWLifting Motor48V3.8kwHydraulic Tank67L ModelGTBZ20AEGross Weight8360kg
