Worm Gear Screw Lift System Rack Jack Pinion Landing Rod Trolley Hand Crank Geared Bottle Reduction Swl Base Shoring Heavy Duty Four Liftin Car Jacks Jack
Hangzhou Xinlan Technology Co., Ltd.- Capacity (Load)：1-10T
- Certification：CE, ISO 9001:2000
- Condition：New
- Min Height：135mm
- Transport Package：Wooden Case
- Trademark：EPT
Base Info
- Model NO.：rack jack-LY
- Origin：Zhejiang China
- Production Capacity：60000000 Piece,Month
Description
Model QJC-1.5B QJC-3B QJC-5B QJC-10B QJC-16B QJC-20B
Rated capacityt 1.5 3 5 10 16 20
Test loadkN 18.4 36.8 61.3 122.5 196 245
Lifting heightmm 350 350 300 300 300 400
Min.start jacking height
Over-bracketmm 725 725 725 800 800 950
Under-bracketmm 70 75 75 85 95 110
Lifting height for the handle turn a ringmm 15 8.5 4.3 5.0 3.5 2.5
The handle pull to lift full loadN 280 310 350 680 680 700
The number of operatorPCS 1 1 1 2 2 2
The handle turning radius Rmm 250 250 250 300 300 300
Dimensions
mmA 125 185 192 242 285 376 B 293 304 330 485 492 505 B1 193 204 232 254 282 295 H 722 724 724 796 798 948 h 68 72 74 82 93 108 L 130 130 130 250 250 250 W 130 130 150 150 160 200 P 140 140 170 170 190 230
Net weightkg 14.5 21 30 49 68 93
