5m Platform Height Manual Pushing Vetical Lift with Tilting Function

Chenlift (Suzhou) Machinery Co., Ltd.
  • After-sales Service：Can Post Spare Parts Within 1 Week
  • Warranty：One Year
  • Application：Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
  • Lift Mechanism：Lift Chain
  • Carrying Capacity：Middle-Level
  • Moves：Manual Pushing

Base Info

  • Model NO.：MT500-1
  • Driven Type：AC
  • Running Mode：Moving
  • Feature：Explosion-Proof
  • Certification：CE, ISO 9001
  • Max Platform Height：4.7 M
  • Max Working Height：6.7 M
  • Load Capacity：150 Kg
  • Platform Size：0.67* 0.66 M
  • Lift/Drive Motor：12V,0.75 Kw
  • Transport Package：Wrapped with Film, Packed in a Pallet, Wooden Case
  • Specification：1.24*0.74*1.99m
  • Trademark：CHEN LIFT
  • Origin：China
  • HS Code：8428909090
  • Production Capacity：3000 Units Per Year

Description

Model MT500-1MT600-1MT800-1MT900-1MT1000-1MT1200-1Loading Capacity150KG150KG150KG150KG136KG120KGPlatform Height4.7M6.2M7.8M9.2M10.4M12MWorking Height6.7M8.2M9.8M11.2M12.4M14MPlatform Size0.67M*0.66M0.67M*0.66M0.67M*0.66M0.67M*0.66M0.67M*0.66M0.67M*0.66MOutrigger Coverage 1.7M*1.7M1.7M*1.7M1.7M*1.7M1.9M*1.7M1.9M*1.7M2.3M*1.9MLift/Drive Motor0.75KW0.75KW0.75KW0.75KW0.75KW0.75KW Details
5m Platform Height Manual Pushing Vetical Lift with Tilting Function5m Platform Height Manual Pushing Vetical Lift with Tilting Function5m Platform Height Manual Pushing Vetical Lift with Tilting Function

Our Service
1. We can design the customized the machines based on your requirement.
2. After knowing your detailed need, the right models will be recommened to you with good price.
3. Shipment can be arranged from our port to your destination port.
4. Opetion video can be sent to you if needed.
5. Parts of machines can be sent to you by express within 7 days if needed.
