Pure-Electric Self-Propelled Scissors Type Hydraulic Fork Lifting Truck
Jiaxing Cavort Hardware Co., Ltd.Base Info
- Model NO.：TY01-ASE
- Application：Workshop Crane, Warehouse Crane
- Lift Mechanism：Telescoping Lift
- Carrying Capacity：Weight Level
- Moves：Self-propelled
- Driven Type：DC
- Running Mode：Moving
- Feature：Explosion-Proof, Insulating
- Certification：GS, CE
- Max Platform Height：6m, 8m, 10m, 11.8m
- Working Height：8m, 10m , 12m , 13.8m
- Horizontal Extension：0.9m
- Load：380kg, 450kg, 320kg, 320kg
- Load of Extension Part：113kg
- Adapted Ground Degree：25%
- Minimun Turning Radius：2.1m, 2.1m, 2.2m, 2.2m
- Folding up Speed：3.0 Km,h
- Rise Speed：0.8 Km,h
- Overall Length：2.43m, 2.43m, 2.43m, 2.43m
- Overall Width：0.81m, 1.15m, 1.15m, 1.15m
- Overall Height：2.18m, 2.31m, 2.42m, 2.55m
- Platform Size：2.27m*0.81m, 2.27*1.12m, 2.27*1.12m, 2.27*1.12m
- Min Distance to The Ground：0.1m
- Drive Wheel Size：381*127mm
- Transport Package：Wooden Case
- Specification：2.27*0.81m, 2.27*1.12m, 2.27*1.12m, 2.27*1.12m
- Origin：China
- HS Code：8427900000
Description
