Niuli Best Seller electric Stacker
Niuli Machinery Manufacture Co., Ltd.- After-sales Service：Online Service
- Warranty：One Year
- Lifting Height：Customized
- Structure：Hydraulic Jack
- Power Source：Electric
- Transport Package：Wooden Case
Base Info
- Model NO.：CTQ
- Specification：NIULI
- Trademark：NIULI
- Origin：Heshan City, Guangdong Province, China.
- HS Code：8427900000
- Production Capacity：20000PCS
Description
Basic Info.
Model NO. CTQ Specification NIULI Trademark NIULI Origin Heshan City, Guangdong Province, China. HS Code 8427900000 Production Capacity 20000PCSProduct Description
1. Capacity: 1000kg, 1300kg, 1500kg. 2000KG2. MAx Lifting Height: 1600mm, 2000mm, 2500mm, 3000mm, 3300mm. 3500-5500MM.
3. Min Forks Height: 85mm.
4. Fork Of Length: 1020mm.
5. Overall Width: 820mm.
6. Charhing Voltage: AC220V.
7. Battery Charger: 24/30/40 (V/A)
Model | CTQ10/16,15/16,20/16 | CTQ10/20,15/20,20/20 |
| Capacity(kg) | 1000/1500/2000 | 1000/1500/2000 |
| Load center(Qmm) | 500 | 500 |
| Front wheel size(mm) | φ80x60 | φ80x60 |
| Rear wheel size(mm) | φ130x55 | φ130x55 |
| Traction wheel(mm) | φ250x80 | φ250x80 |
| Fork Dimensions(L3mm) | 1150x160x60 | 1150x160x60 |
| Max.lifting height(H2mm) | 1600 | 2000 |
| Extended height(H3mm) | 2080 | 2500 |
| Closed height H3(H1mm) | 2080 | 1580 |
| Fork clearance from ground(H5mm) | 80-90 | 80-90 |
| Total length(L1L2mm) | 2070/2360 | 2070/2360 |
| Total width(Bmm) | 815 | 815 |
| Max.fork width(B1mm) | 680 | 680 |
| Turning radius (open pedal)(R1mm) | 1950 | 1950 |
| Self Weight(without battery)(kg) | 710740750 | 730760770 |
| Battery charger | AC220V/50Hz DC24V/40A | AC220V/50Hz DC24V/40A |
