- Model NO.:JK
- Trademark:JEAKUE
- Origin:Anhui
- HS Code:8427109000
- Production Capacity:2000PCS,Month
Item No. | JK8456 | JK8457 | JK8458 |
Performance | Driving type | Power-driven (battery) | Power-driven (battery) | Power-driven (battery) |
Operating type | Walking type | Walking type | Walking type |
Rated load capacity | kg | 1000 | 1000 | 1000 |
Load center distance | mm | 600 | 600 | 600 |
Distance from bearing wheel center to pivot | mm | 750 | 750 | 750 |
Wheel base | mm | 1200 | 1200 | 1200 |
Weight | Weight (including battery) | kg | 410 | 470 | 490 |
Wheel vehicle body | Wheel type | Nylon/polyurethane | Nylon/polyurethane | Nylon/polyurethane |
Size of front wheel | mm | 180×50 | 180×50 | 180×50 |
Size of rear wheel | mm | 100×40 | 100×40 | 100×40 |
Wheels qty(front/rear) | 2/2 | 2/2 | 2/2 |
Tread of front wheel | mm | 680 | 680 | 680 |
Tread of rear wheel | mm | 1020/1300 | 1020/1300 | 1020/1300 |
Base size | Height when door frame draws back | mm | 1990 | 1790 | 2040 |
Lifting height | mm | 1600 | 2500 | 3000 |
Max height of door frame when operating | mm | 1980 | 3030 | 3530 |
Handle height min/max | mm | 790/1156 | 790/1156 | 790/1156 |
Height when pallet fork declines | mm | 70 | 70 | 70 |
Length of vehicle body | mm | 1800 | 1800 | 1800 |
Distance from pallet fork surface to front position | mm | 650 | 650 | 650 |
Width of vehicle body(adjustable) | mm | 1100-1380 | 1100-1380 | 1100-1380 |
Size of pallet fork | mm | 35/100/1150 | 35/100/1150 | 35/100/1150 |
Outside width of pallet fork(adjustable) | mm | 200-800 | 200-800 | 200-800 |
Min ground clearance of vehicle foot center | 35 | 35 | 35 |
Width of right angle stacking passage, pallet 1000×1200(1200laid across pallet fork) | mm | 2250 | 2250 | 2250 |
Width of right angle stacking passage, pallet 800×1200(1200laid along pallet fork) | mm | 2250 | 2250 | 2250 |
Turning radius | mm | 1400 | 1400 | 1400 |
Performance | Lifting speed, (full load/no load) | mm/s | 90/140 | 90/140 | 90/140 |
Declining speed, full load/ no load | mm/s | 120/100 | 120/100 | 120/100 |
Parking brake | Manual | Manual | Manual |
Electronic motor | Watt of lifting electronic motor | kW | 1.5 | 1.5 | 1.5 |
Voltage of battery/ rated capacity | V/Ah | 12/150 | 12/150 | 12/150 |
Weight of battery | Kg | 45 | 45 | 45 |
