Main Specs of Telescopic Boom Lifts

Comply with CE/ANSI/GB Standard

Model

ZT34J

ZT26J

ZT20J

Size

Work Height

36m

28.20m

22.75m

Platform Height

34m

26.20m

20.75m

Horizontal Outreach

23.50m

22.71m

16.80m

A - Stowed Length

13.50m

12.5m

10.36m

B - Stowed Width

2.49m

2.49m

2.49m

C - Stowed Height

3m

2.80m

2.78m

D - Platform Length

2.44m

2.44m

2.44m

E - Platform Width

0.91m

0.91m

0.91m

F - Wheelbase

3.80m

3.05m

2.52m

Wheelbase

2.05/3.41m

2.11m

2.13m

G - Ground Clearance

0.41m

0.40m

0.42m

Performance

Platform Capacity (Unrestricted/Restricted)

300/454kg

300kg/454kg

300kg/454kg

Drive Speed (Working)

5.5km/h

5.5km/h

6.0km/h

Gradeability

45%(24°)

45%   (24°)

45%   (24°)

Turning Radius (Inside)

2.80m

3.66m

2.4m

Turning Radius (Outside)

5.70m

6.86m

5.4m

Turntable Swing

360°continuous

360°continuous

360°continuous

Platform Rotation

±90°

±90°

±90°

Tail Swing

1.88m

1.60m

1.45m

Jib (Range of Articulation)

130°(-55°~75°)

130°(-55°~75°)

135°(-60°~75°)

Max. Working Slope

3°

3°

3°

Max. Wind Speed

12.5m/s

12.5m/s

12.5m/s

Power

Engine

Kohler   KDI2504TCR

Deutz TD2.9 L4/Cummins QSF2.8

Duetz D2.9L4

Fuel Tank Capacity

200L

150L

130L

Control Voltage

12V   DC

12V   DC

12V   DC

Hydraulic Tank Capacity

250L

150L

150L

Drive Mode

4WD

4WD

4WD

Steering Mode

Front-wheel/Rear-wheel/Crab

Front-wheel

Front-wheel

Tire

Type

IN445/50D710
Foam-filled Tires

15-625 Foam-filled Tires

355/55D-625   Foam-filled Tires

Weight

Gross

19200kg

18900kg

12200kg

Highlights

Better work envelop performance, 10% larger than competitor

Zoomlion AWM Remote Monitoring and Rental Management System

Smart telematic control interface with self-diagnostic monitoring capability

Platform dual capacity design, up to 300/454 kg

Smooth & stable boom extension technique controls the minimum stable extending speed at 0.015 m/s

Features

Standard Features

All motion alarm

Horn

Self-closing entry gate

Proportional control

GPS positioning and tracking system

Flashing amber beacon

Auto-leveling system

Remote monitoring and rental management system

Over tilt protection system

Emergency stop button

On-board diagnostic system

Emergency descent system

4.3' LED display

Oscillating axle

Swing-out engine tray

Load sensing system

Accessories & Options

Platform work lights

Anti-collision device

AC power to platform
