Stainless Steel Heavy Duty Air Winch

Yantai Petroleum Machinery Co., Ltd.
  • Type：Construction Winch
  • Driven Type：Pneumatic,Air
  • Carrying Capacity：Weight Level
  • Tonnage：5T
  • Running Mode：Moving
  • Feature：Explosion-Proof

Base Info

  • Model NO.：JQH100
  • Certification：CE
  • Standard：National Standards, API,CCS,ISO9001-2008
  • Transport Package：Iron Boxes or Hard Wooden Cases
  • Specification：API,CCS,ISO,CE certifications
  • Trademark：DA LI
  • Origin：Yantai City, Shandong Province, China
  • HS Code：842539
  • Production Capacity：1000sets Per Month

Description

ItemsParametersWorking Pressure Of Compressed Air(MPa)0.8-1Max. Pull Force (KN)100Max. Wire Rope Speed (m/min)12
Piston Air MotorModelTMH30Rated Power (KW)30Air Consumption (L/s)400
DrumDiameter (mm)300Width= (mm)620Wheel Rim Diamete= (mm)650Rope Diameter=(mm)24Rope Storage=(m)200Air Inlet Diameter (inch)1 1/2"Brake TypeHand Brake and Auto Band Brake
Dimension
 Length (mm)1750Width (mm)1200Height (mm)1250Weight (KG)1450Certifications for Products:

Any questions, needs and quotations are welcome. Expect to your inquiry.
