Truck Crane Qy40k 40ton Mini Truck Mounted Crane for Sale

Evangel Industrial (Shanghai) Co., Ltd.
  • Rated Load：40 Ton
  • Overall Length：13050
  • Overall Width：2800
  • Overall Height：3430
  • Total Weight：40400 Kg
  • Front Axle Load：14500 Kg

Base Info

  • Model NO.：QY40k
  • Rear Axle Load：25900 Kg
  • Engine Model：Wd615.334
  • Engine Rated Power：247 , 2200kw,(R,Min)
  • Engine Rated Torque：1350 , 1400
  • Transport Package：Nude Package
  • Specification：40 ton
  • Trademark：evangel
  • Origin：China Jiangsu
  • Production Capacity：100

Description


DimensionUnitQY40KOverall lengthmm13050Overall widthmm≤2800Overall heightmm3430Weight  Total weight in travelkg40400Front axle loadkg14500Rear axle loadkg25900Power  Engine model WD615.334Engine rated powerkW/(r/min)247 / 2200Engine rated torqueN.m/(r/min)1350 / 1400Travel  Max. travel speedkm/h75Min. turning diameterm≤24Min. ground clearancemm285Approach angle°16Departure angle°11Max. grade ability%46Fuel consumption for 100kmL46Main performance  Max. rated total lifting capacityt40Min. rated working radiusmm3000Turning radius at turntable tailm3.482Max. lifting torquekN.m1400Base boomm10.7Fully extended boomm40.1Fully extended boom+ jibm55.1Longitudinal outrigger spanm5.65Lateral outrigger spanm6.6Working speed  Boom luffing times≤88Boom full extension times≤180Max. swing speedr/min≥2.0Max. speed of main winch (single rope)m/min≥110Max. speed of aux. winch (single rope)m/min≥110

Sunny Feng/ Sales Manager

Evangel Industrial (Shanghai) Co., Ltd.
Evangel International Machinery Ltd.
(CHINESE LEADING CONSTRCUTION MACHINERY AND SPARE PARTS EXPORTER)
Add: Suite 1326, Fortune Times Tower, No. 1438 North Shanxi Road, Shanghai, China

Mobile: +86-18019735352
