• Model NO.：JTC2.5-JTC500
• Structures：Lifting Screw, Worm Shaft, Worm Gear, Housing etc.
• Lifting Screw Diameter：Screw Diameter 14mm-120mm
• Worm Gear Ratios：1,5-1,56
• Stroke Length：Customize Stroke 10-9500mm
• Screw End Fittings：Top Plate, Clevis End, Threaded End, Plain End
• Screw Designs：Translating Screw, Keyed Screw, Rotating Screw
• Mount Types：Upright Mount, Inverted Mount
• System Arrangements：Single Unit or Multiple Units Lifting Systems
• Input Types：Worm Shafts, Motor Flange
• Assembly Drawing：3D Model, 2D Drawing
• Transport Package：Standard Exporting Plywood Cases
• Trademark：JACTON
• Origin：Guangdong, China
• HS Code：8428909090
• Production Capacity：6500sets,Month

Basic Info.

Model NO. JTC2.5-JTC500 Structures Lifting Screw, Worm Shaft, Worm Gear, Housing etc. Lifting Screw Diameter Screw Diameter 14mm-120mm Worm Gear Ratios 1/5-1/56 Stroke Length Customize Stroke 10-9500mm Screw End Fittings Top Plate, Clevis End, Threaded End, Plain End Screw Designs Translating Screw, Keyed Screw, Rotating Screw Mount Types Upright Mount, Inverted Mount System Arrangements Single Unit or Multiple Units Lifting Systems Input Types Worm Shafts, Motor Flange Assembly Drawing 3D Model, 2D Drawing Transport Package Standard Exporting Plywood Cases Trademark JACTON Origin Guangdong, China HS Code 8428909090 Production Capacity 6500sets/Month

Product Description

Motorized screw jacks (also known as a automatic motorized screw jack, a motorized jack screw, a motorised screw jack, or a motorized worm gear screw jack) is used in many fields where it is necessary to lift different loads, such as automated production lines for sheet metal machinery, packaging, textiles, plastics, renewable energy and more. Motorized machine screw jacks with trapezoidal screws have precisely positioning and self-locking feature for no creeping down without brake mechanism or locking systems. Important Note: ball screw jacks are self-lowering without self-locking. Brake motors are required to stopping and precise positioning the load for motorized ball screw jacks. If the motor frequency will be varied to provide a soft start, an inverter duty brake motor may be required.

Screw jacks with motorized drive can be used as a single unit motorized screw jacks or in multiple combinations as perfectly syncronized motorized screw jack lift systems which links two or more screw jacks by drive shafts, couplings and right angle gear boxes. Motor types of motorized screw jacks: three phase induction motor, single phase induction motor, geared motor, stepper motor, servomotor, worm gear motor reducer, air motor or hydraulic motor, dc motor and dc geared motor. All standard motors are 3-phase, 220-380 VAC, 50hz, 1450 rpm. Single phase motors are 220 VAC, 50hz, 1450 rpm. Load capacities of motorized screw jacks: 2.5 kN, 5 kN, 10 kN, 25 kN, 50 kN, 100 kN, 150 kN, 200 kN, 250 kN, 350 kN, 500 kN capacity models.


Company Profiles
JACTON Industry Co.,Ltd (VAT No.: 9144190007026567X3, registered Capital 500000CNY) is a leading manufacturer and supplier of Screw Jacks (Mechanical Actuators), Bevel Gearboxes, Lifting Systems, Electric Linear Actuators, Gearmotors and Speed Reducers, Others Linear Motion and Power Transmission Products in China. We are located in Chang An, Dong guan, Guang dong in China. We are an audited professional manufacturer and supplier by SGS (Serial NO.: QIP-ASI192186) and BV (Serial NO.: MIC-ASR202862) organizations. We have a strict quality system, with senior engineers, experienced skilled workers and practiced sales teams, and consistently provide the customers with the best engineered solution for precision linear actuation, power transmission and mechanical jacking systems. Jacton Industries guarantees quality, reliability, performance and value for today's demanding industrial applications.

Company Advantages
* One of the biggest orders with 1750 units screw lift jacks.
* Standard products with 2D Drawings(DXF, DWG, PDF) and 3D CAD Model(STEP).
* 100% quality assured with double quality inspections. Original Inspection Reports, Operation Manual, and Book Catalogue are put into the packages.
* 100% safety transportation with strong standard export plywood cases materials (free fumigation).
* International standard materials for all standard products.
* Custom design available, OEM service available, Free engineering advice and Customer label available.

Products List
* Manual Screw Jacks
* Electric Screw Jacks
* Screw Jacks Series:
Cubic Screw Jack JTC Series, Machine Screw Jack JTW Series, Trapezoidal Screw Jack JT Series, Worm Screw Jack JTM Series, Stainless Steel Screw Jack JSS Series, Through Hole Screw Jack JTH Series, Ball Screw Jack JTB Series, Cubic Ball Screw Jack JTD Series, Bevel Gear Screw Jack JTS Series, and Electric Cylinder JTE Series.
* Bevel Gearboxes Series:
Cubic Bevel Gearbox JTP Series, Hollow Shaft Gearbox JTPH Series, Input Flange Gearbox JTPF Series, Input Flange and Hollow shaft Gearbox JTPG Series, Stainless Steel Gearbox JTP Series, Aluminum Gearbox JTA Series, and Bevel Gearboxes JT Series.
* Screw Jack Lifting Systems and Accessories:
2jacks lifting system, 3jacks lifting system, 4jacks lifting system, 6jacks lifting system, 8jacks lifting system......14jacks lifting system. Lifting systems accessories cover ac, dc motors, geared motors, servo motors, stepper motors, handwheels, couplings, universal joints, telescopic universal joints, connecting shafts, cardan shafts, limit switches, proximity switches, safety nut, travel nut, rod ends, stop nuts, pillow block bearings, flange blocks, motor flange nema or iec, encoder, potentiometer, frequency converter, position indicators, trunnion plate, and trunnion mounting brackets.
* Electric Linear Actuators Series:
Electro Mechanical Actuators LA Series, Electro Mechanical Actuators LAP Series.
* Gear Reducers Series:
Helical Gear Reducers R Series, Helical Bevel Gear Reducers K Series, Parallel Shaft Helical Gear Reducers F Series, Helical Worm Gear Reducers S Series, Helical Gear Motor GMH/GMV Series, and Worm Gear Reducers NMRV Series.
