Rcs-101 Single Acting Low Height Cylinder
SOV Hydraulic Technology (Shanghai) Co., Ltd.- Type：Hydraulic Jack
- Structure：Hydraulic Jack
- Capacity (Load)：1-10T
- Power Source：Hydraulic
- Max Height：100-150mm
- Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
Base Info
- Model NO.：RCS-101
- Condition：New
- Cylinder Capacity (Ton)：10
- Stroke(mm)：38
- Cylinder Effective Area (Cm2)：14.5
- Oil Capacity( Cm3)：55
- Collapsed Height(mm)：88
- Outside Diameter(mm)：69
- Plunger Diameter：38.1
- Bolt Circle(mm)：26
- Weight(Kg)：4.1
- Cylinder Bore Diameter(mm)：42.9
- Transport Package：Standard Export Wooden Box
- Specification：CE, ISO9001, SGS
- Trademark：SOV
- Origin：Shanghai, China
- HS Code：8412210000
- Production Capacity：5000sets Per Month
Description
Overview
Model
Number Cylinder
Capacity Stroke Cylinder
Effective Area Oil
Capacity Collapsed
Height(A) Extended
Height(B) Outside
Diameter(D) Weight ton (kN) mm cm2 cm3 mm mm mm kg SOV-RCS-101* 10 (101) 38 14,5 55 88 126 69 2,7 SOV-RCS-201* 20 (201) 45 28,7 129 98 143 92 5,0 SOV-RCS-302* 30 (295) 62 42,1 261 117 179 101 6,8 SOV-RCS-502* 45 (435) 60 62,1 373 122 182 124 10,0 SOV-RCS-1002* 90 (887) 57 126,7 722 141 198 165 20,7
Product SpecificationsItem No Company Profile
Number
Capacity
Effective Area
Capacity
Height(A)
Height(B)
Diameter(D)
Product SpecificationsFAQ
