0.25 Ton Intelligent Electric Chain Hoist Balancer with Servo Motor
HENAN BOY MACHINERY CO., LTD.- Application：Single Grinder Crane, Intelligent Electric Hoist Balancer
- Type：Electric Hoist
- Sling Type：Chain
- Lift Speed：>8m,min
- Maximum Lifting Height：6m
- Chain Falls：1
Base Info
- Model NO.：DCH
- Certification：CE, ISO9001:2000
- Condition：New
- Color：Yellow
- Weight：25kg
- Lifting Weight：125-500kg
- Lifting Height：2-6m
- Working Level：M5
- Motor Power：0.75kw
- Motor Speed：3000 Rpm
- Motor Current：4.8A
- Load Continuation Rate：40%
- Dimensions：378X364X772mm
- Transport Package：Non-Fumigation Wooden Box
- Origin：China
- HS Code：8425110000
- Production Capacity：1000 Sets Yearly
Description
Featured Fine Adjustment Function:
Minimum displacement is only 0.3mm.
The control method is handle operation + floating operation. Two operations are automatically switched when holding the handle, and the lifting speed is stepless speed regulation.
Fine adjustment mode: Enter through the button in the lower left corner. The distance of 0.3/0.9/10mm can be adjusted through L/M/H gear.
The control panel button interface and the control panel and servo drive connection line interface adopt XH2.54 connector terminals, modular design.
The 1.3-inch LCD screen can accurately display the weight of the goods and the current mode.
When the heavy object is hovering for more than a certain time (adjustable by pressing the button, 120s by default), the mechanical brake of the motor is turned off and the manual mode is automatically switched to achieve the effect of energy saving and power saving.
Button functions include: minimum and maximum speed adjustment, tare, fine adjustment of gears (three gears), jog up, jog down, hand pressure and hand rest force adjustment.
After the lift is stabilized by operating the handle, it can automatically enter the suspension mode without additional operations.
Servo drive parmeter settings only need to be set before the hoist leaves the factory, no end user adjustment is required.
There is no frustration during the lifting and moving of heavy objects, and the operation is smooth.
If Any Conditions As Below, Please Leave To Our Intelligent Electric Chain Hoist Balancer:
High precision positioning and precision assembly: The constant torque and high responsiveness of the servo motor support reliable and free operability such as precise positioning and assembly.
Need to be operated with both hands: Since the cargo can be carried with both hands, the shaking of the cargo can be suppressed, and it is suitable for up and down assembly operations.
Deal with fragile goods: Through the subtle ultra-low speed movement, fragile items such as glass can also be handled smoothly.
We also provide system lifting solution of intelligent electric chain hoist balancer.
