• Model NO.：HKDH0101S
• Lift Speed：2~8m,min
• Maximum Lifting Height：as Your Requiry
• Chain Falls：1
• Certification：CE, ISO9001:2000, SGS
• Condition：New
• Color：as Your Requiry
• Work Duty：M5
• Feature：Antiseptic
• Running Mode：Moving
• Type of Work：Light Level
• Transport Package：Plywood Cases + Iron Pallets
• Specification：1Ton
• Trademark：ELK
• Origin：China
• HS Code：8425110000
• Production Capacity：5000sets,Month

Basic Info.

Model NO. HKDH0101S Lift Speed 2~8m/min Maximum Lifting Height as Your Requiry Chain Falls 1 Certification CE, ISO9001:2000, SGS Condition New Color as Your Requiry Work Duty M5 Feature Antiseptic Running Mode Moving Type of Work Light Level Transport Package Plywood Cases + Iron Pallets Specification 1Ton Trademark ELK Origin China HS Code 8425110000 Production Capacity 5000sets/Month

Product Description

ELK 1.0 ton electric chain hoist with manual trolley:


Type HKDH0102S

Shell:Light aluminum alloy shell shall be adopted which is light but hard and fit for the use in the terrible work environment with a high heat dissipation rate and all tightness design.
Inverse phase sequence protecting device:it is the special electrical installation which control the circuit not to work in case of wiring error in the power supply.
Limit switch:The limit switch device is installed where the weight is lifted on and off to make the motor to stop outomatically so as to prohibit the chains from exceeding for safety
24V/34V device:it is used to prohibit the emergencies from occurring in case of the leakage in the switch
Side magnetic braking device:The magnetic orce generator is the latest design which is featured for generating magnetic force.it allows instant brake as soon as the electric power is cut off. Thus the braking safety while loading is guaranteed.
Chain bag:it shall be light,handsome and durable.
Chain:The chain shall adopt the imported FEC80 ultra heat-treatable aluminum alloy chain
Hook:it is hot forging with perfect strength that is hard to break.The operation safety of the lower hook is ensured by its 360degrees rotation and safetytongue piece
Support frame:The loading support frame consists of two steel plates,which is extremely sturdy
Electromagnetic contactor:Electromagnetic contactor can be used safely under high frequency
Push button:Waterproof push button is applied.it is light and durable


1. Side magnetic braking device
2. Light but durable chain bag
3. Electromagnetic contactor
4. Inverse phase sequence protecting device
5. Light aluminum alloy shell
6. Limit switch
7. Approved by CE&ISO
8. Chain: FEC 80
9. Prime quality in China

Product Name	Model	Capacity	Lifting Height	Lifting Speed	Chain Dia.* Pitch	Chain Falls	Rotation Speed	Voltage	Power
Electric Chain Hoist	HKDH0102S	1 Ton	3M-100M	6.6  m/min	φ6.3mm *19mm	2Pcs.	1440 R/MIN	200V-600V/3Phase/ 50Hz	1.5KW
Product Name	Model	Capacity	I-Beam Width	Work Grade	/	/	/	/	/
+Manual Trolley	STPC-01	1 Ton	68-130mm	M4	/	/	/	/	/
