Articulated Boom Lift, Self Propelled Professional Electric Scissor Lift
Shandong Match Machinery Co., Ltd.- Application:Workshop Crane, Warehouse Crane, Building Crane
- Lift Mechanism:Scissor Lift
- Carrying Capacity:Weight Level
- Moves:Self-propelled
- Driven Type:AC
- Running Mode:Moving
Base Info
- Model NO.:GTJZ06
- Feature:Insulating
- Certification:CE, ISO 9001
- Lifting Height:6m
- Load Capacity:230kg
- Ground Clearance:0.1m
- Wheelbase:1.31m
- Weight:1415kg
- Transport Package:Wooden Case
- Specification:1.86*0.76*2.18m
- Trademark:Match
- Origin:Shandong, China
- Production Capacity:10sets,Week
Description
Basic Info.
Model NO. GTJZ06 Feature Insulating Certification CE, ISO 9001 Lifting Height 6m Load Capacity 230kg Ground Clearance 0.1m Wheelbase 1.31m Weight 1415kg Transport Package Wooden Case Specification 1.86*0.76*2.18m Trademark Match Origin Shandong, China Production Capacity 10sets/WeekProduct Description
2020 Best 4m-14m Self-propelled electric scissor lift platformApplication
It is widely used for the equipment installations and maintenance at the following places
like construction sites workshops, warehouse, granary, bus/railway stations, hotels, airports, gas station and aerial pipeline.
Introduction
1. Hydraulic System
All machine functions are performed by the hydraulic system. The whole hydraulic system is divided in two parts: one part is used for driving and steering function, the other part is used for platform lifting function.
All the functions are driven by a hydraulic pump, the rate of flow is 16L/min. When the pump is activated, it supplies hydraulic fluid under pressure to the function manifold, where the direction valves and control valves are located. To protect from over pressurization of the hydraulic system, the pump is provided with a pressure relief valve.
2. Electrical System
In this system, Use four six-volt batteries to drive the hydraulic pump and lift function controls. Batteries are charged by external power source.
3. Machine Controls
The machine is equipped with operational controls, which is located in the ground controls box. The controls transfer data through a high-speed data bus.
Product Specifications | GTJZ 06 | GTJZ 08 | GTJZ 10 | GTJZ12 |
working height | 7.8m | 10m | 12m | 13.8m |
platform height | 5.8m | 8m | 10.0m | 12m |
platform height stowed | 1.07m | 1.23m | 1.37m | 1.49m |
platform length | 1.67m | 2.27m | 2.27m | 2.27m |
platform extension length | 0.9m | 0.9m | 0.9m | 0.9m |
platform width | 0.76m | 0.81m | 1.17m | 1.17m |
Overall Height | 2.18m | 2.34m | 2.48m | 2.59m |
Overall length | 1.86m | 2.42m | 2.42m | 2.42m |
Overall Width | 0.76m | 0.81m | 1.17m | 1.17m |
Wheelbase | 1.31m | 1.87m | 1.87m | 1.87m |
Ground Clearance | 0.1m | 0.1m | 0.1m | 0.1m |
Lift capacity | 230kg | 230kg | 320kg | 320kg |
Lift Capacity-Extension Deck | 113kg | 113kg | 113kg | 113kg |
Lift-Up | 27s | 37s | 45s | 50s |
Lift-Down | 22s | 32s | 35s | 38s |
Weight | 1415kg | 2250kg | 2440kg | 2860kg |
Drive Speed(Platform Elevated) | 0-5km/h | 0-3.5km/h | 0-3.5km/h | 0-3.5km/h |
Drive Speed(Platform Lowered) | 0-0.8km/h | 0-0.8km/h | 0-0.8km/h | 0-0.8km/h |
Turning Radius-outside | 0 | 0 | 0 | 0 |
Turning Radius-inside | 1.64m | 2.10m | 2.14m | 2.14m |
Grade ability | 30% | 25% | 25% | 25% |
Maximum Tilt | 3° | 3° | 3° | 3° |
Non-marking solid tires | 15*5 | 15*5 | 15*5 | 15*5 |
Battery | 6v*4/225Ah | 6v*4/225Ah | 6v*4/225Ah | 6v*4/225Ah |
Charger | 30A automatic | 30A automatic | 30A automatic | 30A automatic |
Delivery to some customers for 10m&12m&4m&6m.
Warranty detailsA.Warranty: 12 months warranty apart from man-made faults from receiving the platform liftB. The main parts can be provided for free during the warranty.
C. During the warranty, if the equipment was broken due to the quality itself, we can do the free maintenance and provide the needed spare parts until it can work for normal use. If it is man-made faults, you need pay the material cost.
D. Tires, electric parts do not belong to the scope of warranty
E. We provide all-life long technical support, online and telephone service.
