220V 50Hz 60Hz 500kg 800kg 1500kg Electric Wire Rope Hoist with Trolley
Hebei Pillar Lifting Machinery Manufacturing Co., Ltd.- After-sales Service：Spares
- Warranty：1 Year
- Application：Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane
- Type：Electric Hoist
- Sling Type：Wire Rope
- Lift Speed：5-10m,Min
Base Info
- Model NO.：pa200-pa1500
- Maximum Lifting Height：12m
- Chain Falls：1
- Certification：CE, ISO9001:2000
- Condition：New
- Color：Red
- Key Words：Mini Hoist,Mini Electric Hoist,110V 220V Hoist
- Motor：100% Copper Wire
- Lifting Height：12m 20m 25m 30m
- Model：PA200,PA300,PA400,PA500,PA600,PA800,PA1000,PA1200
- Volt：220V,110V,380V
- Main Feature：High Quality Spraying with CE TUV
- Wire Rope：Steel
- Phase：Single Phase
- Lifting Speed：5-10 M,Min
- Control：Wireless Remote Control or Remote Control
- Plug：Customization
- Hook：Anti-Rotate Type Hook with One Pulley
- Name：500kg 800kg 1500kg Electric Wire Rope Hoist
- Color of Mini Hoist：Customization
- Weight：35kg
- Transport Package：Carton Packing
- Specification：200-1500kg
- Trademark：DLZ or customization
- Origin：China
- HS Code：8425110000
- Production Capacity：500000pieces,Year
Description
Overview
Product Description
Model Usage Rated volt
(v) Input
Power
(w) Rate
Capacity
(kg) Lifting
speed
(m/min) Lifting
height
(m) QTY/CTN
(PCS) Packing Size
(mm) N.W/G.W
(kg) PA200 single hook 480 100 10 12 2 370*290*230 24/26 double hook 200 5 6 PA250 510 125 10 12 double hook 250 5 6 PA300 600 150 10 12 double hook 300 5 6 PA400 950 200 10 12 450*340*260 34/36 double hook 400 5 6 PA500 1020 250 10 12 double hook 500 5 6 PA600 1200 300 10 12 36/38 double hook 600 5 6 PA800 1300 400 10 12 40/42 double hook 800 5 6 PA1000 1600 600 10 12 1 540*245*310 32/34
1. Adopt urgent stop switch and reinforced breaking switch with position limit. Protection class up to IP54, with thermal
protection device.
2. Lifting hook can rotate 360degree
3. Excellent control characteristics, minimal setting force required, designed for one-handed operation.
4. Drop-forged, heat-treated suspension hook and load hook mounted on swivel steel balls with safety latches.
5. Motor insulation is B, magnetic single-phase. Double hook use, single hook use
6. Caged roller bearings on drum center shaft
7. Mini electric hoist speed can reach 10 m / min, the initial design rope length is 12 meters (longer can be customized), the
hook specially designed with advanced settings, greatly increases the lifting weight of the mini electric hoist.
8. Simple structure, easy installation, small size, and single-phase power as a power source.
9. It can be applied in all kinds of locations in industry, business, handicraft industry and service industry not only on the
overhead rails, but also be used in conjunction with many types of electric or manual cranes such as the single-girder crane,
the double-girder crane, the cantilever crane and the gantry crane.
FAQ
-----------
1. Q: Are you a factory or a trading company?
A: We are a factory. We specialize in producing all kinds of Lifting crane, such as mini electric hoist, electric winch, hand
pallet truck, manual hand stacker, electric chain hoist, and stainless steel hoist for more than 10 years.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Baoding City, Hebei Province, China, About 1 hours' drive from Beijing. All our clients, from home or abroad, are warmly welcome to visit us.
3. Q: Can you do OEM ?
A: Yes, we can do OEM products. Any customized size, packaging and logos are welcomed.
4. Q: How do you control your quality ?
A: Quality is priority. Our factory people always attach great importance to quality controlling from the very beginning to the very end:
(1). All raw material we used are environmental-friendly;
(2). Skillful workers care every details in handling the producing and packing processes;
(3). Quality Control Department special responsible for quality checking in each process.
Production process standardization, process standardization, refinement.
5. Q: What are your advantages compared with others?
A: ISO Quality Management System Certificated Factory:
(1).BV, SGS Field Certification and Assessed Factory
(2). Focused on rigging since 2003, Rich experience in Production.
(3). Owned factory, the same quality product, the best price.
(4). Timely Delivery with the support of 3000 square meter warehouse.
(5). Numerous Patents in Rigging Hardware. Be Good at Custom-Made and Shaped Products.
(6). Over 20 Professional Staff in Trading Team, Let's enjoy worry-free and effective communication.
Company Profile
(v)
Power
(w)
Capacity
(kg)
speed
(m/min)
height
(m)
(PCS)
(mm)
(kg)
AC
220/230/
240v
50/60Hz
1. Adopt urgent stop switch and reinforced breaking switch with position limit. Protection class up to IP54, with thermal
protection device.
2. Lifting hook can rotate 360degree
3. Excellent control characteristics, minimal setting force required, designed for one-handed operation.
4. Drop-forged, heat-treated suspension hook and load hook mounted on swivel steel balls with safety latches.
5. Motor insulation is B, magnetic single-phase. Double hook use, single hook use
6. Caged roller bearings on drum center shaft
7. Mini electric hoist speed can reach 10 m / min, the initial design rope length is 12 meters (longer can be customized), the
hook specially designed with advanced settings, greatly increases the lifting weight of the mini electric hoist.
8. Simple structure, easy installation, small size, and single-phase power as a power source.
9. It can be applied in all kinds of locations in industry, business, handicraft industry and service industry not only on the
overhead rails, but also be used in conjunction with many types of electric or manual cranes such as the single-girder crane,
the double-girder crane, the cantilever crane and the gantry crane.
