Low Headroom Electric Chain Hoist
Hangzhou Nante Machinery Co., Ltd.- Application：Double Beam Crane, Gantry Crane, Bridge Crane, Tower Crane, Single Grinder Crane, Lifting Platform, Small Crane, Goods Yard Crane
- Type：Electric Hoist
- Sling Type：Chain
- Lift Speed：>8m,min
- Maximum Lifting Height：12m
- Chain Falls：1
Base Info
- Model NO.：Electric Chain Hoist
- Condition：New
- Color：Yellow
- Driven Type：Electric
- Installation：Special Crane
- Transport Package：Container Box Packing
- Specification：ISO
- Trademark：NANTE
- Origin：Zhejiang China
- HS Code：842511
- Production Capacity：900000 PCS,Year
Description
Low Headroom Electtric Chain Hoist(0.5-5ton)Model 0.5-01 01-01 1.5-01 02-01 02-02 2.5-01 03-01 03-02 03-03 05-02 Lifting Capacity 0.5 1 1.5 2 2 2.5 3 3 3 5 Lifting Speed(m/min) single speed 11.8 6.6 8.8 6.6 3.3 5.4 5.4 4.4 2.2 2.7 Lifting Speed(m/min) double speed 11.8/2.4 6.9/2.3 8.9/2.9 6.8/2.3 3.3/1.1 5.4/1.8 5.4/1.8 4.5/1.5 2.3/0.8 2.7/0.9 Lifting Height(m) Standard lifting height is 3m, Can be customized 1-130M Load Chain Diameter(mm) Φ6.3 Φ7.0 Φ10.0 Φ10.0 Φ7.1 Φ11.2 Φ11.2 Φ10.0 Φ7.1 Φ11.2 Lifting Motor Power(Kw) 0.8 1.5 3 3 1.5 3 3 3 1.5 3 rotate speed(r/min) 1440 1440 1440 1440 1440 1440 1440 1440 1440 1440 Motor of Lifting phase 3 3 3 3 3 3 3 3 3 3 voltage(V) 220-690 220-690 220-690 220-690 220-690 220-690 220-690 220-690 220-690 220-690 frequency(Hz/s) 5CV60 50/60 50/60 50/60 50/60 50/60 50/60 50/60 50/60 50/60 Lifting Motor Power(Kw) 0.4 0.4 0.4 0.4 0.4 0.75 0.75 0.75 0.75 0.75 rotate speed(r/min) 1440 1440 1440 1440 1440 1440 1440 1440 1440 1440 Motor of Traveling Traveling Speed(m/min) 11/21 11/21 11/21 11/21 11/21 11/21 11/21 11/21 11/21 11/21 phase 3 3 3 3 3 3 3 3 3 3 voltage(V) 220-690 220-690 220-690 220-690 220-690 220-690 220-690 220-690 220-690 220-690 frequency(Hz/s) 5CV60 50/60 50/60 50/60 50/60 50/60 50/60 50/60 50/60 50/60 I-Beam Width(mm) 58-153 58-153 82-178 82-178 82-178 100-178 100-178 100-178 100-178 100-178
