Buytool Skid Lifter Powered Scissor Pallet Truck with 800mm Lifting Height

Wuxi Buytool Industrial Equipment Co., Ltd.
  • Application：Workshop Crane, Shipboard Crane, Warehouse Crane, Building Crane
  • Lift Mechanism：Scissor Lift
  • Carrying Capacity：Weight Level
  • Moves：Moving
  • Driven Type：AC
  • Running Mode：Moving

Base Info

  • Model NO.：PEL100L
  • Feature：Explosion-Proof
  • Certification：CE, ISO 9001
  • Capacity：1000kg, 500kg
  • Min. Height：85mm
  • Max. Height：830mm
  • Load Center：560mm
  • Color：Customizable
  • Net Weight：188kg
  • Type：Lift Table
  • Certificate：Ce Approved
  • Scissor：Scissor Lift Table
  • Transport Package：1PC,Wooden Case
  • Specification：customizable
  • Trademark：Buytool
  • Origin：Made in China
  • HS Code：8427900000
  • Production Capacity：3000PCS,Month

Description

Battery-OperatedLoad Capacity(kg)5005001000100050050010001000Min. Fork Height(mm)8888888888888888Max. Fork Height(mm)830830830830833833833833Fork/Platform Length(mm)11151115111511151115111511151115Fork/Platform Width(mm)526690526690538703538703Individual Fork Width(mm)153153153153153153153153Load Center(mm)560560560560560560560560Front Load Roller(mm)φ70×68,PUSteering Wheel(mm)φ150×40,PUOverall Length(mm)16201620174017401620162017401740Overall Width(mm)580740550720586752556726Overall Height(mm)10501050130713071050105013071307Power Pack(KW)1.61.61.61.61.61.61.61.6Battery(V)1212121212121212Working Cycles(s)10010080801001008080Net Weight(kg)172176174180180184182188Platform Without PlatformWith Platform
Buytool Skid Lifter Powered Scissor Pallet Truck with 800mm Lifting Height

Buytool Skid Lifter Powered Scissor Pallet Truck with 800mm Lifting Height


FAQ:

Q: What about the quality of the products?
A: Our products are CE approved, and we have five inspection steps before shipment:
1. Inspect the raw material in accordance with ISO9001;
2. Strict inspection in the whole production process;
3. Load limit test when assembling finished;
4. 100% strict inspection of products before shipment;
5. If needed, inspection by buyer.

Q: How long is the quality guarantee?
A: All of our products carry one-year warranty.

Q: What's the leadtime?
A: Normally 30 days.
If you order more than 5 itmes mixed in one container, it will be 45 days.
If you order one item in one container, it will be 20 days.
