• Model NO.：YBC0.2-10
• Feature：Explosion-Proof
• Certification：CE, ISO 9001
• Type：Hydraulic Aluminum Chain Lift
• System：Hydraulic+Chain
• Material：Aluminum Alloy
• Mobile：4 Wheels
• Power：1.1kw
• Platform Size：1400*600mm
• Weight：660kg
• Install：Underground
• Lift System：Hydraulic System
• Transport Package：Iron Case or Plywood Case Package
• Specification：Aluminum Alloy
• Trademark：SDLIFT
• Origin：Shandong China
• HS Code：84289090
• Production Capacity：5000 Set Per Year

Model

Support column

Load capacity

Platform size

Lift height

Power

Total dimension

Weight

SJYL0.1-6

one

100kg

550×550mm

6m

    1.1kw

1260×800×1900mm

340Kg

SJYL0.2-6

two

200kg

1050×550mm

6m

1.1kw

1360×820×1900mm

520Kg

SJYL0.2-8

two

200kg

1100×550mm

8m

1.1kw

1480×820×1980mm

580Kg

SJYL0.2-10

two

200kg

1400×600mm

10m

1.1kw

1780×890×2080mm

660kg

SJYL0.2-12

two

200kg

1400×600mm

12m

1.1kw

1860×1150×2150mm

860kg

SJYL0.2-14

three

200kg

1470×800mm

14m

2.2kw

1750×1220×2250mm

1040kg

SJYL0.2-16

four

200kg

1470×800mm

16m

2.2kw

1900×1280×2250mm

1400kg

SJYL0.2-19

four

150kg

1560×850mm

19m

2.2kw

2550×1500×2250mm

1800kg

Safety:
1) Explosion-proof lock valve to avoid a sudden drop if emergency occurs.
2) The safety rails to guarantee safety of the people above platform.
3) The limit switch system helps the aluminum lift to stop at accurate position.
4) Electricity leakage protection device is equipped on, all electric components are CE certified.
5) All the aluminum lift are passed 1.2 times loading test before leaving factory.
Our Services
1) We can design the customerized aluminum lift as per your requirement.
2) The most suitable aluminum lift will be recommended to you once we got your requirement.
3) Shipment can be arranged from our port to your destination port.
4) Operation video can be sent to you if needed.
5) User-friendly English manual for machine installation using and maintenance.
6) Two year warranty for whole machine without man-made faults.
7) We will send you parts for free if there are any non-human factors faults during warranty time.
8) Supply 24-hours technical assistance by email, telephone or other communication online.
9) We could reply you in 2 hours after received your any questions even on weekend and holiday. Engineers are available to your country if necessary.
