4-12 Meters Height Hydraulic Self-Propelled Scissor Lift Table
Jinan Aos International Co., Ltd- After-sales Service：Spare Parts Within One Year
- Warranty：1year
- Application：Warehouse Crane
- Lift Mechanism：Scissor Lift
- Carrying Capacity：Weight Level
- Moves：Self-propelled
Base Info
- Model NO.：GTJZ-8
- Driven Type：Hydraulic
- Running Mode：Moving
- Feature：Explosion-Proof, Insulating
- Certification：CE, ISO 9001
- Max Platform Height：8m
- Load Capacity：450kg
- Platform Size：2.5*1.15*1.83m
- Platform Extend Reach：0.9m
- Platform Extend Load：113kg
- Min Ground Clearance：0.1m
- Wheelbase：1.89m
- Turning Radius (Inside/Untside)：Turning Radius (Inside)(M)
- Gradeability：25%
- Lifting Motor：24V,4.5kw
- Lifting Speed：3-5m,Min
- Driving Speed (Stowed)：3.5km,H
- Driving Speed(Raised)：0.8km,H
- Battery Group：4*6V,225ah
- Charger：24V,30A
- Transport Package：Plywood Case Packing
- Specification：8m
- Origin：China
- HS Code：8428909090
- Production Capacity：50000PCS,Year
Description
Overview
Product Parameters
Detailed PhotosMain Features Workshop Show
