• Model NO.：as requirement
• Lifting Eye Type：Flat Eye
• Rope Core Type：Steel Core
• Power Source：Lever
• Shape：Flat
• Certification：ISO 9001
• Sling Color：Red
• Name：Load Binder
• Technics：Forging
• Quality Certification：ISO9001:2008
• OEM and ODM：100%
• Welcome：Custom Design
• Export Markets：Global
• Shipping Port：Qingdao Port
• Unique：China Gold Supplier
• Packaging：Wood Case
• MOQ：10-1000PCS
• Free Sample：Yes
• Logo Printing：Customized
• Custom Made：Yes
• Inner Package：Carton Box, Plastic Bag
• OEM Service：Yes
• Transport Package：Plywood Box
• Specification：1,4-5,16, 5,16-3,8, 3,8-1,2, 1,2-5,8
• Trademark：ShengAo
• Origin：Shangdong, China
• HS Code：7325109000
• Production Capacity：500ton,Month

Item Name

General Products
Application / Service Area

Metal Parts Solution for Vehicle, Agriculturemachine, Construction Machine, transportation equipment, Valve and Pump system. Such as scraper conveyor chain, engine bracket, truck chassis bracket, gear box , gear housing , gear cover, shaft, spline shaft , pulley, flange, connection pipe, pipe, hydraulic valve , valve housing ,Fitting , flange, wheel, flywheel, oil pump housing, starter housing, coolant pump housing, transmission shaft , transmission gear, sprocket, chains etc.

Main blank Process for Forged parts

Forging , Press

Blanks Tolerance

+/-0.3~+/-2 mm

Applicable Material

Carbon steel, Low Carbon steel, middle carbon steel, 40Cr, 20CrMnTi, 20CrNiMo etc.

Forging Blank Size /Dimensions

142 mm- 300mm or according to customer requirement

Blanks Weight

Range from 0.1kg-1000kg

 Applicable Machining Process

CNC Machining/ Lathing/ Milling/ Turning/ Boring/ Drilling/ Tapping/ Broaching/Reaming etc.

 Machining Tolerance

From 0.005mm-0.01mm-0.1mm

Machined Surface Quality

Ra 0.8-Ra3.2 according to customer requirement

Applicable Heat Treatment

Normalization , quenching and tempering, Case Hardening, Nitriding, Carbon Nitriding, Induction Quenching

Applicable Finish Surface Treatment

Shot/sand blast, polishing, Surface passivation, Primer Painting , Powder coating, ED- Coating, Chromate Plating, zinc-plate, Dacromat coating, Finish Painting,

     1. Chain size: 8~16mm
     2. W. L. L.: 4000~16000daN
     3. MBL: 8000~32000daN
     4. Standard: EN12195-3
     5. Hooks c/w safety latches
     6. Easy functioning.
     7. In combination with Grade 80 chain.

        * Type: ratchet  type.with hook and pin
        * Material: Alloy steel / Carbon steel.
        * Surface finish: Painted.
        * High quality load binder with drop Forged steel body
        * Alloy Grab hook is durable for lashing chain.
        * Hot-Treated ratchet is more robust. Heavy duty steel safety hooks.
        * Simple to assemble with chains without using any intermediate coupling links
        * Customized sizes are welcome
        * Any other types: EN12195-3 Ratchet load binder, lever type load binder, spring load binder,
        Indirect load binder, claw type load binder, chain tie down...Etc.



       European type ratchet load binder:
       1. Safety, reliable design for easy operation.
       2. No requirement for locking of handle than lever type load binders.
       3. High quality drop forged construction.
       4. Heat treated for extra strength.
       5. Short reach hooks provide optimum take-up.
       6. Each binder individually proof tested.
       7. Cradle grab hook with safety pin is available upon request



       Q: Why choose Shengao product?
       A: We shengao have our own plant Weifang Shengao machinery Co., Ltd, therefore, we
       can surely promise the quality of every product and provide you comparable price.

       Q: Do you provide OEM Service?
       A: Yes, we provide OEM Service.

       Q: Do you provide customized products?
       A: Yes. Customers give us drawings and specifications, and we will manufact accordingly.

       Q: What is your payment term?
       A: We provide kinds of payment terms such as L/C, T/T, Paypal, Escrow, etc.


      If there's anything we can help, please feel free to contact with us.
