• Model NO.：KRM143A
• Specification：KRM143A
• Trademark：Fenghu
• Origin：China

L(mm)W(mm)H(mm)X(mm)MASS(kg)1180402340391120







Hoist Cylinder KRM143

Working Pressure   (MPa)

               (Kgf/cm²)

6.4







Gear Pump KP-55

Standard Revolution

(rpm)

800

65

Inner Diameter     (mm)

140

Discharge Volume(ml/rev.)

55

Stroke            (mm)

520

Max. Testing Pressure     (MPa)

 (Kgf/cm²)



20.6

Min. Close distance (mm)

795

210

Piston Rod Diameter   (mm)

70



Weight(kg)



13

Max. pressure     (MPa)

               (Kgf/cm²)

14.7

150



Hoist Mounting and Maximum Lifting Capacity



Recommended Truck G.W.(kg)

Body Length(mm)

Rear Overhang(mm)

Distance between Load Center to Hinge(mm)

Distance between trunion to Hinge(mm)

Rated Lifting Capacity(kg)

Designed Max. lifting Capacity(kg)

(including load weight)

6000-9000

3400

400

1300

1100

4000-5000

8500/60°
