• Model NO.：YJP100
• Tonnage：10T
• Reel Number：1
• Running Mode：Moving
• Feature：Explosion-Proof
• Certification：CE, ISO 9001
• Standard：National Standards
• Line Pull Capacity：98kn , 10000kg , 22000lbs
• Line Speed (1st Layer)：7 M,Min
• Oil Pressure：17 MPa
• Oil Flow：60L,Min
• Drum Capacity：59m
• Wire Rope Diameter：18mm
• Net Weight：262kg
• Transport Package：Plywood Case
• Specification：390*190*340
• Trademark：ZHONGXIN
• Origin：China
• HS Code：84253990
• Production Capacity：5000PCS Every Year

Basic Info.

Model NO. YJP100 Tonnage 10T Reel Number 1 Running Mode Moving Feature Explosion-Proof Certification CE, ISO 9001 Standard National Standards Line Pull Capacity 98kn / 10000kg / 22000lbs Line Speed (1st Layer) 7 M/Min Oil Pressure 17 MPa Oil Flow 60L/Min Drum Capacity 59m Wire Rope Diameter 18mm Net Weight 262kg Transport Package Plywood Case Specification 390*190*340 Trademark ZHONGXIN Origin China HS Code 84253990 Production Capacity 5000PCS Every Year

Product Description

Our winches are used on rescue and recovery vehicles, cargo truck, trailers and heavy equipment transporters, armoured flighting vehicles, off-load vehicles, tractors, loaders and earthmovers, fire engines, high tension line stringing rigs and many other applications.

YJP100 hydraulic winch mainly consists of a planetaty reducer, arrester, drum, hydraulic motor, etc. Due to its use of the floating -typed planetary reducer, the winch makes the operation more stable and the structure more reasonable, its use of multidisc-typed friction brake make the torque large, safe and reliable. In brief introduction, the product is featured by its small size, compact construction and high transmission efficiency.

STRUCTURAL CHARACTERISTICS:

* Full floated-typesd planetary gear reducer makes the operation more stable, the structure more reasonable.

* Adopt the multidisc-typed friction normally-closed arrester makes the brake torque larger, safer and more reliable.

*The product is featured by its small size, compact construction and high transmission efficiency.

*Free wire releasing function

*Adopt imported motor with long use life.

*The installation bracket can be manufactured according to the customer's requirement.

* Adopt the manual, pneumatic clutch equipment

*Manufacture according to GJB82-86 National *Winch Standard

PERFORMANCE PARAMETERS SHEET:

Max. Pull force(bottom layer): 98KN

Working speed(bottom layer): 7m/min

Response pressure of arrester: 2.5MPa

Pressure: 17MPa

Flux: 60m/min

Drum diameter*bottom diameter *length: 390*190*340mm

Wire volume: 59m

Weight: 262Kg

Suggested high-intensity wire rope diameter: 32mm
