Iron Lifting Platform (AS Series)

Hardlift Equipment Co., Ltd.
  • Application：Workshop Crane, Warehouse Crane
  • Lift Mechanism：Scissor Lift
  • Carrying Capacity：200~350kg
  • Moves：Vehicular
  • Driven Type：DC
  • Running Mode：Stationary

Base Info

  • Model NO.：AS20; AS30; AS50; AS80; AS35D
  • Certification：GS, CE
  • Net Weight：44~125kg
  • Transport Package：Pallet Loading
  • Specification：AS20; AS30; AS50; AS80; AS35D
  • Trademark：Hardlift
  • Origin：China
  • HS Code：87168000
  • Production Capacity：12000PCS,Year

Description

Basic Info.

Model NO. AS20; AS30; AS50; AS80; AS35D Certification GS, CE Net Weight 44~125kg Transport Package Pallet Loading Specification AS20; AS30; AS50; AS80; AS35D Trademark Hardlift Origin China HS Code 87168000 Production Capacity 12000PCS/Year

Product Description

Lift Table (AS Series):

* Economic range but reliable.
* New design to meet norm EN1570: 1999.
* New hydraulic system increases safety and protects your goods,
Stepless rate of lowering system remains irrespective of the weight
Of the load.
 Model    AS20   AS30   AS50   AS80   AS35D
 Capacity   (kg) 200   300   500   800   350
 Table Size   LXW (mm) 700X450   852X502   852X502   920X520   920X520
 Table Height   Hmin/HmaX (mm) 265/755   330/910   390/910   442/1000   435/1500
 Handle Height   h (mm) 980   1100   1100   1130   1130
 Wheel Dia.   (mm) Φ100   Φ125   Φ125   Φ150   Φ150
 Overall Size   BXC (mm) 450X870   502X1050   502X1050   520X1170   520X1170
 Foot Pedal to MaX. Height    ≤25   ≤30   ≤40   ≤70   ≤70
 Net Weight   (kg) 44   74   81   114   125
