Electric Wire Rope Hoist Winch 30ton

Pingyang Construction Hoisting Machinery Co.
  • Type：Electric Winch
  • Driven Type：AC
  • Speed：Slow
  • Carrying Capacity：Weight Level
  • Tonnage：3T
  • Reel Number：1

Base Info

  • Model NO.：JM30
  • Running Mode：Stationary
  • Feature：Insulating
  • Certification：ISO 9001
  • Standard：Nonstandard
  • Motor：ABB or Normal Brand
  • Transport Package：wooden case
  • Specification：JM-5Ton
  • Trademark：CH
  • Origin：china
  • HS Code：842531900
  • Production Capacity：10000unit,year

Description

ModelJM2JM3JM5JM8JM10Line pull capacity (kg)200030005000800010000average speed (m/min)121010109Wire rope(mm):12.515.521.52630Reduction boxTypeJZQ350JZQ350JZQ400JZQ500JZQ650Transmission ratio23.3431.523.3431.540.17Drum (mm)Diameter/mm273325406500550Length4805206459001000Capacity(m)150180250300450motorTypeYZ160M2-6YZ160M2-6YZ160L-6YZR225M-8YZR250M1-8Power(kW)7.57.5112230Rotate speed(r/min)948948953720720Hydraulic BrakeYWZ-200/25YWZ-200/25YWZ-300/45YWZ-300/45YWZ-300Equipment Dimension (mm)1060x1500x7501600x1100x8201400x1910x9502050x1640x10002470x2280x1180Weight(kg)630680140030004000Electric Wire Rope Hoist Winch 30tonElectric Wire Rope Hoist Winch 30tonElectric Wire Rope Hoist Winch 30tonElectric Wire Rope Hoist Winch 30tonElectric Wire Rope Hoist Winch 30ton
