Hydraulic Electric Ramp Garage Equipment Lifting Table Truck Container Work Platform Adjustable Loading Telescoping Lifter Dock Ramp Leveler
Shanghai Xifei Door Industry Co., Ltd.- After-sales Service：Yes
- Warranty：12 Months
- Lift Mechanism：Hydraulic Cylinder
- Carrying Capacity：6t , 8t , 10t
- Moves：Stationary
- Driven Type：Hydraulic
Base Info
- Model NO.：XF-O-2500
- Running Mode：Stationary
- Feature：Explosion-Proof
- Certification：CE, ISO 9001
- Voltage：220V 50Hz , 380V 50Hz
- Power：0.75 Kw , 1.5kw
- Transport Package：Wrapping Film
- Specification：2000*2000*600 mm
- Trademark：XIFEI
- Origin：Made in China
- HS Code：84254290
- Production Capacity：10000, Year
Description
MORE PARAMETERSMain Board Q235B steel plate with anti-slide pattern,thickness:6 / 8 mm;blasting surface treatment and powder coating Lap Plate Q235B steel plate with anti-slide pattern,thickness:14 / 16mm;The surface treatment is blasting and powder coating Hinge Open type, 8*150mm Loading Weight Dynamic load:6T / 8T / 10T / 12 T / 15T Driving Electrohydraulic, Local brand / ARGO HYTO powerpack, 380V 0.75KW ~ 1.5KW Control System Standard 380V English interface Adjust Scope +400mm/-300mm Adjust Time Up ≤16S ; Down≤10S Sealing Parts Brand:NOK A505 Complete set of seals for oil cylinder Main cylinder Single cylinder / double cylinders Main Board Stiffener 8 pcs of 14# I-Beam, the height of Beam is 140mm Support Rod Fold at the bottom of the panel High Pressure Oil Pipe T3683-2001;60mpa Side Baffles Automatic retraction to ensure safety Hydraulic Oil 32# Antiwear hydraulic oil Working Pressure of Hydraulic Oil 8Mpa ±1Mpa Capacity of Hydraulic Oil Tank 5-6L Working Temperature -30ºC~+50ºC Anti-collision Bumper 300*200*100 mm Base Frame 10#channel steel welded frame structure Safety Part Explosion proof valve Working Frequency ≥200000 times
Remarks:
1. Shanghai XIFEI Door Industry Co., Ltd is a professional enterprise engaged in industrial door design, manufacturing,
sales & installation and after-sales service.
2. The company introduces advanced equipment and technology, design a variety of products according to customer
needs, aims to support customers with high-quality products and professional solutions.
3. The company mainly produce steel door, wood door, fire door, high speed door, sectional door, roller shutter door,
hangar door, logistic docking system and so on.
4. Honors and Certifications:
a. China AAA Enterprise
b. ISO9001: 2000 Management Certification
c. CE Certification
